Siemens 6ES5102-8MA02
€750.00
excl. VAT
Product condition:
New, old stock
Unused goods from older stock. Original packaging, if present, may have been opened. Manufacturing date and packaging may vary; age- or storage-related marks are possible. 14-day right of return in the event of a defect. See Terms and Conditions
- Available · Ships in approx. 3–6 business days
- Urgent? Faster options such as direct or express shipping are often possible. Please state your required date when you request a quote or order.
Do you have any questions?
Personal service
We are happy to help with processing, shipping or individual quotations. Simply contact us:
Online and available Currently unavailable
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
A RAM memory for 2048 instructions belongs to the Siemens 6ES5102-8MA02, the CPU 102 for the SIMATIC S5-100U control system. For program execution, 32 counters and 32 timers are also available. The input and output data distinguish between a maximum of 256 digital and a maximum of 16 analog I/O. These are the capacity limits of the control system, not a number of connection terminals directly present on the CPU. When assigning it to an existing S5-100U controller, both the CPU designation and the complete order number 6ES5102-8MA02 must therefore be taken into account. On the input side, the module is rated at 24 V direct voltage. The output voltages are +9 V at V1 and +5.2 V at V2. The front has a 15-pin Sub-D socket as well as separate indicators labelled RUN and STOP. The operating mode switch is marked RUN, STOP and COPY. The CPU 102 is offered for the specific order with shipping from Germany to the United States and other international destinations. In the battery area, BATTERY OFF and LOW are present as indicator labels. The battery compartment is marked 3.4 V and 850 mAh. The supply terminals on the lower front are labelled L+, M and the ground symbol. The battery compartment is located next to the Sub-D socket; below it are the battery indicator and its switch. The operating mode switch sits below the RUN/STOP indicators. The dimensions of the module are 91.5 × 135 × 120 mm. No net or gross reference is assigned to the weight specification of 0.65 kg.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | SIMATIC S5 |
| Manufacturer / order / ident number | 6ES5102-8MA02 |
| Device type | CPU 102 |
| System assignment | S5-100U |
| RAM memory capacity | 2048 instructions |
| Counters | 32 |
| Timers | 32 |
| Digital inputs/outputs | Max. 256 |
| Analog inputs/outputs | Max. 16 |
| Supply voltage | 24 V DC at the input |
| Output voltages | +9 V (V1); +5.2 V (V2) |
| Connection | 15-pin Sub-D socket |
| Operating status indicators | RUN and STOP |
| Operating mode switch | RUN / STOP / COPY |
| Battery indicator | BATTERY OFF / LOW |
| Battery compartment marking | 3.4 V; 850 mAh |
| Dimensions | 91.5 × 135 × 120 mm |
| Weight (reference not specified) | 0.65 kg |
Product status and export data
| Product status (manufacturer) | End of life since 01/10/2022 |
|---|---|
| Commodity code | 85371091 |
| Country of origin | Germany |
| Export list number (AL) | N |
| ECCN | N |
Manufacturer information for order number 6ES5102-8MA02, as of 20/10/2026. Not a statement about the individual unit supplied; does not replace an export control review.
