Siemens 6ES7633-1DF02-0AE3
€1,610.00
excl. VAT
Product condition:
Used, removed from an installation
The item comes from dismantled equipment. We have not carried out an electrical inspection or a comprehensive operational check. Signs of age, use, installation or removal may be present. 14-day right of return in the event of a defect. See Terms and Conditions
- Available · Ships in approx. 1–2 business days
- Urgent? Faster options such as direct or express shipping are often possible. Please state your required date when you request a quote or order.
Do you have any questions?
Personal service
We are happy to help with processing, shipping or individual quotations. Simply contact us:
Online and available Currently unavailable
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
In the Siemens 6ES7633-1DF02-0AE3, the CPU 315, OP7 and IM360 belong to a common SIMATIC-C7 compact unit. The C7-633/P combines control functions of the S7-300 with a text-based operator interface. Its backlit LCD shows four lines of 20 characters each; the character height is 8 mm. The keyboard comprises 16 function keys and four softkeys. For the control functions, 48 kbyte of work memory with 16 K instructions in RAM are available. The integrated RAM load memory amounts to a maximum of 80 kbyte, and the FEPROM expansion is described up to 512 kbyte. The integrated I/O includes 16 digital inputs and 16 digital outputs. In addition, there are four analog inputs, four analog outputs and four universal inputs. The digital outputs have a rated current of 0.5 A per output and electronically clocked short-circuit protection. The nominal supply is 24 V DC; the permissible supply range extends from 20.4 to 30.2 V DC. Separately from this, the permissible range of the load voltage L+ is 20.4 to 28.8 V DC. The current consumption is typically 550 mA and at most 1 A, and the typical power loss is 12 W. For an order with this C7-633/P compact unit, shipping from Germany to the United States and other international destinations is part of the specific order. The housing has degree of protection IP20, the front IP65. With vertical installation, the operating ambient temperature is 0 to +50 °C, with installation at 45 degrees it is 0 to +45 °C. The complete outer dimensions are 240 × 203.5 × 90 mm. The mounting cutout, by contrast, measures 231 × 159 mm. The weight is approx. 1.8 kg; its reference basis is not explicitly stated.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | SIMATIC C7-633/P, S7-300 |
| Manufacturer/order/ident number | 6ES7633-1DF02-0AE3 |
| Device type | Compact control and operator unit |
| Control function | CPU 315, OP7 and IM360 integrated |
| Work memory | 48 kbyte; 16 K instructions RAM |
| RAM load memory | max. 80 kbyte integrated |
| FEPROM load memory | expandable up to 512 kbyte |
| Digital inputs/outputs | 16 DI, 16 DO |
| Analog inputs/outputs | 4 AI, 4 AO |
| Universal inputs | 4 |
| Display | Backlit LCD, 4 × 20 characters, 8 mm character height |
| Function keys | 16 function keys and 4 softkeys |
| Supply voltage | 24 V DC; 20.4–30.2 V DC |
| Current consumption | typ. 550 mA; max. 1 A |
| Power loss | typ. 12 W |
| Degree of protection | Housing IP20; front IP65 |
| Operating temperature | vertical 0–50 °C; 45° installation 0–45 °C |
| Dimensions | 240 × 203.5 × 90 mm |
| Weight (reference basis not stated) | 1.8 kg |
Export data
| Commodity code | 85371091 |
|---|---|
| Country of origin | Germany |
| Export list number (AL) | N |
| ECCN | N |
Manufacturer information for order number 6ES7633-1DF02-0AE3, as of 15/10/2026. Not a statement about the individual unit supplied; does not replace an export control review.
