Siemens 6SN1123-1AB00-0CA3
€510.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Siemens 6SN1123-1AB00-0AA0 combines two motor axes in a 50 mm wide power module of the SIMODRIVE 611 series. The power electronics have a transistor current rating of 15 A and feature internal cooling. For motors of the 1FT5 series, the rated current is 7.5 A; for 1FT6 motors, it is 5 A. This specific current allocation is one of the most important distinguishing features within the 6SN1123 family. The module forms the power stage of the modular drive system. Its two axes are controlled via a separate control unit, while the power module provides the motor currents. For asynchronous motors, a rated current of 5 A and a peak current of 8 A are specified; for synchronous motors, a rated current of 5 A and a peak current of 10 A are available. The internal cooling dissipates the heat loss within the module structure. The system supply voltage is in the range of 380 to 480 V AC. The ambient temperature range is specified as 0 to 40 °C during operation and 0 to 50 °C for storage; relative humidity remains limited to up to 80 percent without condensation. The module width of 50 mm determines the space requirement in the device row. The net weight is approximately 2.88 kg. For technical classification, the number of axes, current class, cooling type, and respective motor series are considered together. Similar 6SN1123 modules differ despite having the same basic design due to differences in the number of axes, output current, or cooling. The full suffix 1AB00-0AA0 distinguishes this two-axis 15-A version from more powerful power modules and later revisions in the drive system. Control units, supply modules, and motor connections are independent system components and not part of the item identifier.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product Series | SIMODRIVE 611 |
| Manufacturer/Order/ID Number | 6SN1123-1AB00-0AA0 |
| Device Type | Power Module |
| Module Role | Power stage in modular drive system |
| Axes | 2 |
| Transistor Current | 15 A |
| Motor Rated Current 1FT5 | 7.5 A |
| Motor Rated Current 1FT6 | 5 A |
| Rated Current Asynchronous Motor | 5 A |
| Peak Current Asynchronous Motor | 8 A |
| Rated Current Synchronous Motor | 5 A |
| Peak Current Synchronous Motor | 10 A |
| Cooling Type | Internal Cooling |
| Supply Voltage | 380–480 V AC in drive system |
| Operating Temperature | 0–40 °C |
| Storage Temperature | 0–50 °C |
| Dimensions | Module width 50 mm |
| Weight | approx. 2.88 kg |
Related products
Go to shop
Siemens 6SN1123-1AA00-0EA2
€890.00
Siemens 6SN1145-1BA01-0BA0
€1,520.00
Siemens 6SN1146-1AB00-0BA1
€460.00
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What motor currents apply to Siemens 6SN1123-1AB00-0AA0?
For 1FT5 motors, the rated current is 7.5 A; for 1FT6 motors, it is 5 A; the module's transistor current is 15 A.
How many axes and what cooling type does the power module have?
The assembly has two axes; the cooling type is internal and the module width is 50 mm.
