Product description
Control Techniques UNI2401 belongs to the classic Unidrive series and has frame size 2. The variable frequency drive operates on three-phase 380–480 V AC at 48–62 Hz. Rated power is 5.5 kW or 7.5 HP. Continuous output current is 12 A at 40 °C ambient temperature. Typical input current is 13 A and maximum input current is 16 A. Control methods include open loop, closed-loop vector, servo and regeneration. Available switching frequencies are 3 kHz, 4.5 kHz, 6 kHz, 9 kHz and 12 kHz. The enclosure has IP20 protection. Ambient temperature is 0–40 °C and extends to 50 °C with derating. An axial fan provides forced-air cooling. The tall rectangular enclosure carries the display, operating keys and device marking on its front. Power and control terminals occupy separate areas, while the rear forms the mounting plane. Power stage, control electronics, fan and heat sink remain within the outer contour. For frame size 2, the guide specifies a height including surface-mounting brackets of 366 mm, a width of 190 mm and a depth of 200 mm. Complete external dimensions are 190 × 366 × 200 mm. Documented device weight is 8 kg. Manufacturer, product series and type number are Control Techniques, Unidrive Classic and UNI2401.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Control Techniques |
|---|---|
| Product series | Unidrive Classic |
| Manufacturer / order / identification number | UNI2401 |
| Frame size | Frame size 2 |
| Rated output power | 5.5 kW (7.5 HP) |
| Input voltage | Three-phase 380–480 V AC ±10 % |
| Input frequency | 48–62 Hz |
| Typical input current | 13 A |
| Maximum input current | 16 A |
| Continuous output current | 12 A at 40 °C |
| Control modes | Open loop, closed-loop vector, servo and regeneration |
| Switching frequency | 3 kHz / 4.5 kHz / 6 kHz / 9 kHz / 12 kHz |
| Degree of protection | IP20 |
| Ambient temperature | 0–40 °C; up to 50 °C with derating |
| Cooling | Forced-air cooling with axial fan |
| Dimensions | 190 × 366 × 200 mm (W × H × D) |
| Weight | 8 kg |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the dimensions and weight of Control Techniques UNI2401?
Complete external dimensions are 190 × 366 × 200 mm; documented frame-size 2 weight is 8 kg.
What are the power ratings of Control Techniques UNI2401?
Rated power is 5.5 kW, continuous output current is 12 A and typical input current is 13 A.
