Product description
The Heidenhain 355253-01 commutating reactor is designated KDR 150. The specification set is three-phase. Its nominal voltage is 3× 400 V AC and its nominal current is 3× 72 A. An inductance of 1 mH is specified for each of the three phases. The reactor operates on 50/60 Hz networks and has a power loss of approx. 350 W at nominal operation. Its open construction has an IP 00 rating and is cooled by natural convection. An active fan or liquid-cooling circuit is not part of the assembly. The connection side is arranged with three inputs U1, V1 and W1 and outputs U2, V2 and W2. The stated system assignment is the regenerative UVR 150 D supply unit. Identification number, current rating and inductance distinguish this reactor from the adjacent KDR 140 and KDR 160 sizes. The mechanical drawing shows a maximum height of 287 mm, a width of 250 mm and a depth of 155 mm. Complete external dimensions are therefore 155 × 250 × 287 mm in depth × width × height order. Weight is approx. 23 kg. The mechanical data also state the mounting points and terminal arrangement. The variant data comprise number 355253-01, designation KDR 150, 3× 400 V AC, 3× 72 A, 1 mH and the UVR 150 D system reference.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Heidenhain |
|---|---|
| Product series | KDR Series |
| Manufacturer / order / identification number | 355253-01 |
| Product name | Commutation reactor |
| Rated voltage | 3× 400 V AC |
| Rated current | 3× 72 A |
| Inductance | 1 mH |
| Frequency | 50/60 Hz |
| Power dissipation | Approx. 350 W |
| Protection rating | IP 00 |
| Number of phases | 3 |
| Device assignment | UVR 150 D converter module |
| Field of use | Heidenhain converter systems for machine tools |
| Cooling method | Natural convection |
| Dimensions | 155 × 250 × 287 mm (D × W × H) |
| Weight | approx. 23 kg |
