Product description
ERBG075D01K9 is an external brake resistor from the Lenze ERBG series. Its rated resistance is 7.5 Ω, rated power is 1.90 kW and thermal capacity is 285 kWs. During braking, the resistor absorbs electrical energy from the DC bus and converts it into heat. The assignment table lists it for Lenze drive modules in the 400-V class. Typical assigned motor powers include 45.0 kW and 55.0 kW; the specific combination follows the respective drive table. The component consists of a ventilated metal enclosure with an integrated resistor element and a separate terminal area. The complete ERBG075D01K9 type code distinguishes resistance, continuous power and construction from other ERBG versions. Mechanical data are listed separately in the accessory table. It states a height of 486 mm, a width of 236 mm and a depth of 302 mm. In fixed depth × width × height order, complete external dimensions are therefore 302 × 236 × 486 mm. The tabulated weight is 9.5 kg. Rated resistance, rated power, thermal capacity, type number and enclosure dimensions describe this exact resistor version. The terminal area and enclosure openings form part of the stated external contour.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Lenze |
|---|---|
| Product series | Lenze ERBG brake resistors |
| Manufacturer / order / identification number | ERBG075D01K9 |
| Thermal capacity | 285 kWs |
| Voltage class | 400/480 V |
| Rated resistance | 7.5 Ω |
| Rated power | 1.90 kW |
| Drive class 1 | 40.0 HP / 30.0 kW |
| Drive class 2 | 50.0 HP / 37.0 kW |
| Drive class 3 | 60.0 HP / 45.0 kW |
| Function | Absorption of braking energy |
| System reference | Drive peripherals |
| Construction | External brake resistor |
| Dimensions | 302 × 236 × 486 mm (D × W × H) |
| Weight | 9.5 kg |
