Lenze 00401423
€100.00
Shipping information
Do you require same-day delivery or express shipping with a defined delivery time for this item?
Please contact us!
Product description
The Lenze EVS9321-EP is a Global Drive 9300 servo positioning controller for precise single axes in automated machinery. The EP version combines the power stage of a 0.37-kW servo controller with positioning functions for absolute and relative movements, homing, manual operation, and S-shaped ramps. The unit is designed for three-phase mains with a permissible voltage range from 320 to 528 V and 45 to 65 Hz; alternatively, the DC link can be supplied with 460 to 740 V DC. At 400 V and 50/60 Hz, the output power is 1.0 kVA. Rated output current is 1.5 A at 8 kHz or 1.1 A at 16 kHz switching frequency. For 200-percent overcurrent operation, the system manual specifies a maximum of 3.0 A at 8 kHz and 2.2 A at 16 kHz. The IP20 built-in unit measures approximately 78 × 350 × 250 mm and weighs 3.5 kg. It can operate from 0 to 40 °C without derating. The Lenze system bus connects additional servo controllers and input/output terminals to the control architecture. For a like-for-like replacement, the EVS9321-EP designation, device version, installed feedback, motor and mains connections, communication modules, parameter sets, and machine wiring are decisive. Cooling, mounting position, fuse sizing, and installed mains filters must also suit the existing system. The controller is therefore particularly suitable as a spare part for existing 9300 positioning axes where the mechanics, motor, encoder, and application program are to remain in use. Before commissioning, transfer the backed-up parameters and current axis configuration to the replacement unit in a controlled process.
Specifications
| Manufacturer | Lenze |
|---|---|
| Product series | Global Drive 9300 |
| Manufacturer/order/identification number | EVS9321-EP |
| Device type | Servo positioning controller |
| Motor power | 0.37 kW |
| Mains supply | 3 AC; 320–528 V; 45–65 Hz |
| Alternative DC-link supply | 460–740 V DC |
| Rated mains | 3 AC 400/480 V; 50/60 Hz |
| Output power at 8 kHz | 1.0 kVA |
| Rated output current at 8 kHz | 1.5 A |
| Rated output current at 16 kHz | 1.1 A |
| Maximum output current at 8 kHz | 3.0 A in 200-% overcurrent operation |
| Maximum output current at 16 kHz | 2.2 A in 200-% overcurrent operation |
| Positioning modes | Absolute and relative positioning |
| Positioning functions | Homing, manual positioning, and S-ramps |
| Communication | Lenze system bus for controllers and input/output expansions |
| Degree of protection | IP20 |
| Operating temperature | 0 to +40 °C without derating |
| Dimensions | 78 × 350 × 250 mm |
| Weight | 3.5 kg |
Related products
Go to shop
Machine downtime?
Faster delivery
Is your machine down and do you require particularly fast delivery? Tell us directly. We will do everything possible to provide a quotation with the fastest available delivery and find a solution that matches your schedule.
Our highest priority is to keep your production processes running. Rely on our expertise and flexible service to minimise machine downtime effectively.
Contact us now!Product safety
Manufacturer / EU responsible person
What function does the Lenze EVS9321-EP perform?
The EVS9321-EP combines a servo controller with positioning functions for absolute and relative movements, homing, and manual positioning. It is intended for individual controlled axes within the Lenze 9300 system.
What must be checked when replacing an EVS9321-EP?
Compare the complete type number, device version, motor and encoder data, feedback system, communication modules, mounting situation, mains connection, parameter set, and machine wiring with the installed controller.
