Siemens 1FT5064-0AG01-2-Z
€390.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Within the 1HU3 range, the Siemens 1HU3102-0AD01-Z is classified as a permanent-magnet DC servomotor for SIMODRIVE feed drives. The complete identifier denotes the 1HU3102 frame size with electrical version 0AD01; the public product name retains the suffix -Z without listing individual option identifiers. A tachogenerator captures the speed feedback signal. For the exact basic version, 18 Nm torque and a maximum speed of 1,200 min⁻¹ are specified. Additional documentation for the same basic variant lists 1.5 kW rated power and 173 V DC. The cylindrical shaft has a keyway and a diameter of 32 mm. The square flange measures 190 × 190 mm. These data describe the mechanical and electrical core of the motor without deriving additional equipment features from the -Z suffix. Natural air cooling is part of the documented motor version. The feedback system uses a tachogenerator rated at 20 mV per min⁻¹. The SIMODRIVE documentation describes the 1HU range together with transistorised DC converters for four-quadrant feed drives. The associated drive architecture processes the tachogenerator actual value in the speed control loop. The combination of the 190-mm flange, 32-mm shaft, and 510-mm housing length defines the installation geometry; the power connection and tachogenerator feedback remain functionally separate motor circuits within the motor assembly. The exterior dimensions of the equivalent 0AD01 basic version are 510 mm long, 190 mm wide, and 190 mm high. Based on the frame size, housing volume, and comparison values for the 1HU3102 range, a conservative approximate weight of 55 kg is used for handling. The full Siemens identifier 1HU3102-0AD01-Z remains authoritative for the product identity.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product range | Siemens SIMODRIVE 1HU3 |
| Manufacturer/order/identification number | 1HU3102-0AD01-Z |
| Device type | DC servomotor |
| Excitation type | Permanent-magnet excited |
| Rated power | 1.5 kW |
| Voltage | 173 V DC |
| Torque | 18 Nm |
| Maximum speed | 1,200 min⁻¹ |
| Speed feedback | Tachogenerator, 20 mV per min⁻¹ |
| Shaft | Cylindrical with keyway, Ø 32 mm |
| Flange | 190 × 190 mm |
| Cooling | Natural air cooling |
| Dimensions | 510 × 190 × 190 mm (L × W × H) |
| Weight | approx. 55 kg |
Related products
Go to shop
Siemens 1FT5104-0AC74-2-Z
€2,830.00
Siemens 1HU3071-0AC01-Z
€890.00
Siemens 1FT6064-6AC71-4AG0
€1,420.00
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the basic electrical and mechanical data of Siemens 1HU3102-0AD01-Z?
The basic data include 1.5 kW rated power, 173 V DC, 18 Nm torque, and a maximum speed of 1,200 min⁻¹. The cylindrical shaft with keyway has a diameter of 32 mm.
What feedback system and exterior dimensions does the 0AD01 version have?
Speed feedback is provided by a tachogenerator rated at 20 mV per min⁻¹. The equivalent 0AD01 basic version measures 510 × 190 × 190 mm, and the flange measures 190 × 190 mm.
