Siemens 6ES7422-7BL00-0AB0 SIMATIC S7-400 SM 422
€130.00
Do you require same-day delivery or express shipping with a defined delivery time for this item?
Please contact us!
Siemens 3TK2827-1BB41 is a SIRIUS safety relay for installed machinery and control cabinets using emergency-stop or safety-related relay circuits with a 24 V DC supply. The Siemens data sheet describes a 45 mm base unit with relay enabling circuits, screw terminals and monitored start. Siemens 3TK2827-1BB41 provides two instantaneous NO safety contacts, two delayed NO safety contacts and one NC signalling contact. The delayed enabling circuits have an adjustable switch-off delay from 0.05 to 3 s, allowing use in safety circuits requiring a defined run-down time. Safety ratings include SIL3 to IEC 61508 and Performance Level e for instantaneous enabling, plus SIL2 and Performance Level d for delayed enabling; category 4 is also documented. The device supports single- or dual-channel input wiring, cross-circuit detection, a feedback input and a start input. Electrical data includes 300 V rated insulation voltage, 4,000 V impulse withstand voltage, 5 A thermal contact current and switching capacity up to 5 A at 24 V DC or 230 V AC. Additional replacement criteria include IP20 at the enclosure and terminals, finger-safe construction, any mounting orientation, screw or snap mounting, and dimensions of 44.8 x 138.5 x 120 mm. This relay suits existing SIRIUS-3TK28 circuits where contact arrangement, delay time, start logic and terminal technology must remain unchanged. The complete 3TK2827-1BB41 identifier and EN ISO 13849-1 classification must remain aligned with the safety documentation.
| Manufacturer | Siemens |
|---|---|
| Manufacturer/Order/Identification number | 3TK2827-1BB41 |
| Product series | SIRIUS 3TK28 |
| Type code | 3TK2827-1BB41 |
| Equipment type | Safety relay with relay enabling circuits |
| Control voltage | 24 V DC |
| Device width | 45 mm |
| Instantaneous safety contacts | 2 NO |
| Delayed safety contacts | 2 NO |
| Signalling contact | 1 NC |
| Switch-off delay | Adjustable from 0.05 to 3 s |
| Start function | Monitored start |
| Instantaneous safety level | SIL3 / PL e |
| Delayed safety level | SIL2 / PL d |
| Input wiring | Single- or dual-channel |
| Thermal contact current | max. 5 A |
| Connection type | Screw terminals |
| Dimensions | 44.8 x 138.5 x 120 mm |
