Product description
The Danfoss FC-102P37KT4P55H1 is a VLT HVAC Drive FC 102 frequency converter for ventilation, heating, air-conditioning and refrigeration applications. The P37K version is rated for a typical motor shaft output of 37 kW or 50 hp at 460 V and operates on a three-phase 380 to 480 V AC mains supply. In normal-overload operation, the drive provides 110 percent output current for one minute. Continuous output current is 73 A at 380 to 439 V and 65 A at 440 to 480 V; intermittent ratings are 80.3 and 71.5 A respectively. Continuous apparent output power is 50.6 kVA at 400 V and 51.8 kVA at 460 V. The P55 type code denotes an IP55 or UL Type 12 enclosure with backplate. Danfoss assigns enclosure size C1 to this power and protection-rating version. The integrated H1 RFI filter meets Class A1/B or Category C1. This configuration is therefore prepared for protected industrial use in demanding HVAC systems. Maximum input current is 66 A in the lower and 59 A in the upper voltage range. For thermal planning, the relevant values are an estimated power loss of 739 W at maximum rated load, an efficiency of 0.98 and a unit weight of approximately 45 kg. The converter can be used, for example, to control the speed of suitable fan, pump or compressor motors in existing systems. Before replacement, compare the complete type code, motor data, mains voltage, EMC version, protection rating, installation dimensions, terminal assignment, optional modules and parameter settings with the installed drive system. Installation and commissioning must only be performed by qualified electrical personnel in accordance with the current Danfoss documentation.
Specifications
| Manufacturer | Danfoss |
|---|---|
| Product series | VLT HVAC Drive FC 102 |
| Manufacturer/order/identification number | FC-102P37KT4P55H1 |
| Device type | Frequency converter for HVAC applications |
| Application areas | Ventilation, heating, air conditioning and refrigeration |
| Rated motor power | 37 kW / 50 hp at 460 V |
| Mains voltage | 3 × 380–480 V AC |
| Ingress protection / enclosure | IP55 / UL Type 12 with backplate (P55) |
| RFI filter | H1, Class A1/B (C1) |
| Overload capacity | 110 % for 1 min |
| Enclosure size | C1 for IP55 / UL Type 12 |
| Continuous output current 380–439 V | 73 A |
| Continuous output current 440–480 V | 65 A |
| Intermittent output current | 80.3 A at 380–439 V / 71.5 A at 440–480 V |
| Apparent output power 400 V | 50.6 kVA |
| Apparent output power 460 V | 51.8 kVA |
| Maximum input current | 66 A at 380–439 V / 59 A at 440–480 V |
| Estimated power loss | 739 W at maximum rated load |
| Weight | approx. 45 kg at IP55 |
| Efficiency | 0.98 |
Related products
Go to shop
Machine downtime?
Faster delivery
Is your machine down and do you require particularly fast delivery? Tell us directly. We will do everything possible to provide a quotation with the fastest available delivery and find a solution that matches your schedule.
Our highest priority is to keep your production processes running. Rely on our expertise and flexible service to minimise machine downtime effectively.
Contact us now!Product safety
Manufacturer / EU responsible person
Which applications is the Danfoss FC-102P37KT4P55H1 intended for?
The VLT HVAC Drive FC 102 is intended to control the speed of suitable motors in ventilation, heating, air-conditioning and refrigeration systems. The P37K version covers 37 kW on a three-phase 380 to 480 V supply.
What does P55 mean in the type code?
P55 denotes an IP55 or UL Type 12 enclosure with backplate. Danfoss assigns enclosure size C1 to this 37-kW version.
