Product description

The Heidenhain 605374-92 is a sealed incremental linear scale from the LS 477 series with a measuring length of 1020 mm. The system operates according to the photoelectric scanning principle on a DIADUR glass scale with a grating period of 20 μm. The integrated 50-fold interpolation produces a signal period of 0.4 μm and supports measurement steps of 0.1 μm with 4-fold evaluation in the downstream electronics. The Heidenhain 605374-92 provides an accuracy of ±5 μm over the entire measuring length — suitable for use in numerically controlled machine tools, grinding and milling centres and boring mills. The output signal is TTL-compatible (A+, A−, B+, B−, R+, R−) with selectable reference marks in the 50-mm grid. For the ML range up to 1020 mm two reference marks are provided, each 35 mm from the beginning or end of the measuring length. The scale operates from 5 V ±5 % and has a no-load current consumption of less than 140 mA. A separate adapter cable (1 m, 3 m, 6 m or 9 m) connects the scale to the terminal block; cable lengths up to 100 m are permitted with Heidenhain cable. With a maximum travel speed of 48 m/min and an shock resistance of up to 300 m/s² (IEC 60068-2-27) the device is designed for demanding machine environments. The protection rating is IP 53 when installed as intended, or IP 64 when used with the DA 300 sealing-air unit. The operating temperature range extends from 0 °C up to +50 °C. Directly available from our warehouse in Germany.

Heidenhain 605374-92

Specifications

Manufacturer Heidenhain
Product series LS 477
Type code 605374-92
Measurement type Incremental
Measurement principle Photoelectric, DIADUR glass scale
Measurement length (ML) 1020 mm
Accuracy ±5 μm
Graduation period 20 μm
Signal period 0.4 μm (50-fold integrated interpolation)
Output signal TTL (A+, A−, B+, B−, R+, R−)
Supply voltage 5 V ±5 %
Current consumption (idle) < 140 mA
Maximum traverse speed ≤ 48 m/min
Degree of protection IP 53 (mounted); IP 64 (with DA 300 sealing air)
Operating temperature 0 °C to +50 °C
Cooling method None (passive, no active cooling)
Weight approx. 0.9 kg
