Product description

Heidenhain 671706-05 is the AK ERM 2280 scanning head for modular angle-measuring systems with 5200 signal periods. As the scanning element in an ERM-2280 system, it uses the MAGNODUR magnetoresistive principle to generate an analogue sinusoidal signal with an amplitude of ~1 VSS. This interface supports high-dynamic positioning tasks in direct drives, rotary tables and rotary axes of machining centres. Supply voltage is DC 5 V ±0.5 V, and typical current consumption is ≤ 150 mA without load. A cut-off frequency of ≥ 300 kHz supports control loops with high scanning rates. The head is rated IP67 under EN 60529 for protection against coolant, lubricant and dust in the machine environment. Connection to the downstream electronics uses a 12-pin M23 coupling. With HEIDENHAIN system cables, the maximum cable length is ≤ 150 m. A TTR-ERM-2200C measuring drum with an outside diameter of 326.90 mm is used for the 5200 signal periods. Maximum permissible mechanical drum speed is ≤ 4500 min⁻¹. The head withstands vibration under EN 60068-2-6 at ≤ 400 m/s2 and shock under EN 60068-2-27 at ≤ 1000 m/s2. Its operating-temperature range is –10 °C to +60 °C. Net weight is approximately 30 g without the connecting cable. Compare the complete Heidenhain 671706-05 identification before replacement. The modular, bearingless design requires no separate bearing assembly. Available directly from our warehouse in Germany.

Heidenhain 671706-05

Specifications

Manufacturer Heidenhain
Product series ERM 2280 series
Type code 671706-05
Component Scanning head (AK)
Signal periods 5200
Interface ~1 VSS (sinusoidal)
Power supply DC 5 V ±0.5 V
Power consumption ≤ 150 mA (without load)
Limit frequency (-3 dB) ≥ 300 kHz
Measuring-drum outside diameter 326.90 mm
Graduation period ≈ 200 μm
Electrical connection M23, 12-pin
Maximum drum speed ≤ 4500 min⁻¹
Protection rating IP67 (EN 60529)
Vibration resistance ≤ 400 m/s2 (EN 60068-2-6)
Shock resistance ≤ 1000 m/s2 (EN 60068-2-27)
Operating temperature –10 °C to 60 °C
Cooling method Natural convection
Weight ≈ 30 g (without connecting cable)
