Heidenhain 1181313-05
€1,250.00
Do you require same-day delivery or express shipping with a defined delivery time for this item?
Please contact us!
When an encoder on a rotary axis or rotary table must be replaced with the same Heidenhain assembly, the complete type sequence is decisive. The Heidenhain ERM 280 offered here is a ring-shaped angle encoder for installed measuring systems using version 1024 03S12-03 R with ID 393000-22. ERM systems are typically mounted directly on rotating axes and provide the position signal without deriving it from motor data, which is particularly relevant for precise indexing and swivelling movements. Replacement therefore depends not only on the basic product series but on the exact combination of graduation, signal type, mechanical construction and marked version. Before ordering, compare the ring diameter, scanning unit, cable exit, installation position and identification of the existing unit. Heidenhain ERM 280 is not a universal retrofit kit for arbitrary machines; it is a variant-specific spare for installed Heidenhain measuring chains. On older machines, the correct replacement can preserve the parameterisation, subsequent electronics and mechanical mounting. The existing electronics must expect the same 1 Vpp signal and graduation, as small differences can require additional work on the control and mechanics. For maintenance teams, this exact match is often more important than selecting a merely similar encoder family. A unit bearing the same type sequence is intended to restore position feedback on the installed axis. Available directly from our warehouse in Germany.
| Manufacturer | Heidenhain |
|---|---|
| Product series | ERM 280 |
| Type code | ERM 280 |
| Product type | Angle encoder |
| ID number | 393000-22 |
| Signal type | ~1 Vpp |
| Graduation | 1024 |
| Version code | 03S12-03 |
| Direction of rotation | R |
| Design | Ring-shaped / modular |
| Mounting note | For an existing ERM-280 installation |
| Cooling method | Not required |
| Weight | Not specified |
