Lenze E82EV153K4B201
€920.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
The Lenze E82EV223_4B200 is an 8200 vector frequency inverter rated at 22 kW. The documented supply-voltage range is 3/PE AC 320–550 V at 45–65 Hz. A DC supply of 450–775 V DC is also specified. Rated output current is listed as 30 A at 8 kHz and 43 A at 4 kHz. Maximum output current is 70.5 A for 60 s. Output power is documented as 32.6 kVA and the output-frequency range as 0–650 Hz. For overload capacity, the data lists 150 % for 60 s and 210 % for 3 s. The device has degree of protection IP20, power loss of 640 W and forced cooling. The complete E82EV223_4B200 type code identifies the specific 8200 version of the product series. In the Lenze product catalogue, E82EV223K4B2xx is explicitly listed as the version without a mains filter. The B200 suffix belongs to this B2xx group. For the version without a mains filter, the variant-specific table specifies 250 × 350 × 250 mm in height × width × depth order and a mass of 15 kg. In the canonical width × height × depth order, the outside dimensions are 350 × 250 × 250 mm. The existing number sequence is therefore assigned to the correct axis order, while the documented manufacturer value now supersedes the previous approximate weight. The values refer to the individual base unit without a mains filter, operating module, connection cables, external components or shipping packaging. Width, height, depth and device mass appear together in the same catalogue table. Electrical ratings, overload data, protection rating, power loss and cooling remain separate technical characteristics. The specification table ends with the documented outside dimensions and device weight.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Lenze |
|---|---|
| Product series | 8200 vector |
| Manufacturer/order/identification number | E82EV223_4B200 |
| Rated power | 22 kW |
| Mains voltage | 3/PE AC 320–550 V, 45–65 Hz |
| DC supply | 450–775 V DC |
| Rated output current (8 kHz) | 30 A |
| Rated output current (4 kHz) | 43 A |
| Maximum output current (60 s) | 70.5 A |
| Output power | 32.6 kVA |
| Output frequency | 0–650 Hz |
| Overload capability | 150 % for 60 s; 210 % for 3 s |
| Protection rating | IP20 |
| Power dissipation | 640 W |
| Cooling method | Forced cooling |
| Dimensions | 350 × 250 × 250 mm (W × H × D) |
| Weight | 15 kg |
