Lenze E94AZPS0074N
€290.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
The Lenze E94AZPS0034N provides the mechanical and electrical base for a Single Drive axis module in the 9400 HighLine series. The documented axis-module assignment lists E94ASxE0024, E94ASxE0034 and E94ASxE0044. The mounting base receives the respective axis module and provides the designated connection points. A DC-bus fuse is specified at 16 A / 700 V DC. The CAN system bus is located directly on the backplane. Installation uses a DIN rail; the connection design is described as plug-in and tool-free. The enclosure corresponds to IP20, while cooling uses natural convection. An ambient operating range from 0 °C to +40 °C is documented. The compact assembly belongs to the modular Lenze Servo Drives 9400 HighLine structure. Type code, axis-module class and electrical version identify the specific variant. E94AZPS0034N is listed without an integrated brake module and remains distinct from backplanes with a different current class or brake module. Product identification therefore uses the complete type code together with the designation of the axis module. External dimensions and weight are the final entries in the specification table and refer to the complete backplane.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Lenze |
|---|---|
| Product series | Lenze 9400 HighLine |
| Manufacturer / order / identification number | E94AZPS0034N |
| Device type | Installation backplane (Single Drive) |
| Axis module assignment | E94ASxE0024 / E94ASxE0034 / E94ASxE0044 |
| DC-bus fuse | 16 A / 700 V DC |
| System bus | CAN on board |
| Mounting method | DIN-rail mounting |
| Degree of protection | IP20 |
| Ambient temperature | 0 °C to +40 °C |
| Connection type | Plug-in / tool-free |
| Cooling method | Natural convection |
| Dimensions | 460 × 60 × 120 mm (L × W × H) |
| Weight | 0.88 kg |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the dimensions and weight of Lenze E94AZPS0034N?
External dimensions are 460 × 60 × 120 mm in length × width × height order; weight is 0.88 kg.
