Lenze EVF8610-E-V013
€150.00
Do you require same-day delivery or express shipping with a defined delivery time for this item?
Please contact us!
The Lenze EVF8611-E belongs to the frequency inverter series 8600 and corresponds to the device class 8611 or 33.8611_E. For this class, Lenze documents 22 kW rated power, 47 A rated output current and maximum 94 A output current. The apparent power is 32.6 kVA at 400 V and 39.1 kVA at 480 V. On the mains side, the manual states 41 A current consumption. The three-phase AC input range is from 330 to 528 V at 45 to 65 Hz; alternatively, the intermediate circuit can be supplied with 470 to 740 V DC. The output voltage can be set between 0 V and the respective mains voltage, the output frequency range extends from 0 to 480 Hz. The switching frequency is factory set to 4 kHz and can be selected between 2 and 16 kHz. A brake chopper response threshold of 765 V DC is documented for braking operation. The power loss of the 8611 class is 740 W. The built-in device has protection class IP20. For the device group 8608 to 8611, Lenze states 360 × 500 × 300 mm and a weight of 28.5 kg. The mechanical installation is vertical with the terminal strip underneath and a free cooling air path. The manual lists radio interference suppression filters separately in the accessories chapter; for 8611 the external filter EZF3_050A004 is assigned there. This accessory assignment is crucial for EMC planning and the existing control cabinet structure. Before replacing, the complete type code, mains or intermediate circuit supply, current class, switching frequency, brake circuit, installation space and existing external filter components must be checked together.
| Manufacturer | Lenze |
|---|---|
| Product series | Lenze 8600 |
| Manufacturer/order/identification number | EVF8611-E |
| Device type | Frequency converter |
| Rated power | 22 kW |
| Rated output current | 47 A |
| Maximum output current | 94 A |
| Apparent power | 32.6 kVA at 400 V; 39.1 kVA at 480 V |
| AC input voltage | 3 × 330–528 V |
| Mains frequency | 45–65 Hz |
| Alternative DC link supply | 470–740 V DC |
| Mains power | 41 A |
| Output voltage range | 0 V to mains voltage |
| Output frequency range | 0–480 Hz |
| Switching frequency | 4 kHz factory; 2–16 kHz adjustable |
| Brake chopper response threshold | 765 V DC |
| Power loss | 740 W |
| Protection class | IP20 |
| Dimensions (W × H × D) | 360 × 500 × 300 mm |
| Weight | 28.5 kg |
