Product description
Graphical process visualisation and direct touch operation define the Mitsubishi Electric E1101. This operator panel belongs to the E1000 Series and uses a 10.4-inch TFT-LCD with 800 × 600 pixels and 64.000 colours. The active display area measures 211.2 × 158.4 mm. Its touchscreen consists of polyester on glass; its documented service life is 1 million finger actuations. The application has 12 MB of memory including fonts. In addition to the public type number E1101, Beijer Electronics lists part number 603221123. The communication equipment includes two serial interfaces: RS232C and RS422/RS485. A shielded RJ45 connection provides 10/100-Base-T Ethernet. A Type A USB host and a Type B USB device port operate according to USB 1.1; the host is specified for a maximum of 500 mA. One slot accepts CompactFlash cards of Type I or II. Supply voltage is 20 to 30 V DC and maximum power consumption is 12 W. These details describe the documented hardware equipment of E1101; they do not state which software is installed, which accessories are included or whether the functional condition has been tested. The front is specified as IP66, while the rear is IP20. For panel installation, the cut-out is 265 × 206 mm. The complete housing measures 302 mm in width, 228 mm in height and 64 mm in depth. Device weight is 2.1 kg. The type number E1101 remains the decisive public identity feature. Condition, scope of delivery and availability depend solely on the specific offer and are not derived from the technical manufacturer data.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Mitsubishi Electric |
|---|---|
| Product range | E1000 Series / E Series |
| Manufacturer/order/identification number | E1101 |
| Beijer part number | 603221123 |
| Device type | Graphic touch HMI / Operator panel |
| Display | 10.4-inch TFT-LCD |
| Resolution and colours | 800 × 600 pixels, 64.000 colours |
| Active display area | 211.2 × 158.4 mm |
| Touchscreen | Polyester on glass; 1 million finger actuations |
| Application memory | 12 MB including fonts |
| Serial interfaces | RS232C and RS422/RS485 |
| Ethernet | 1 × 10/100 Base-T, shielded RJ45 connection |
| USB | USB host Type A and USB device Type B, USB 1.1; host maximum 500 mA |
| Memory card interface | CompactFlash Type I/II |
| Supply voltage | 20 to 30 V DC |
| Power consumption | maximum 12 W |
| Degree of protection | Front IP66, rear IP20 |
| Panel cut-out | 265 × 206 mm |
| Dimensions | 302 × 228 × 64 mm (W × H × D) |
| Weight | 2.1 kg device weight |
