Pilz 474894
€470.00
excl. VAT
Product condition:
New, old stock
Unused goods from older stock. Original packaging, if present, may have been opened. Manufacturing date and packaging may vary; age- or storage-related marks are possible. 14-day right of return in the event of a defect. See Terms and Conditions
- Available · Ships in approx. 1–2 business days
- Urgent? Faster options such as direct or express shipping are often possible. Please state your required date when you request a quote or order.
Do you have any questions?
Personal service
We are happy to help with processing, shipping or individual quotations. Simply contact us:
Online and available Currently unavailable
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Five safety contacts as N/O contacts and two different auxiliary contacts characterise the Pilz 474894 from the PNOZ 3 series. One auxiliary contact is an N/C contact, the other an N/O contact with passing function. Its terminals are numbered 73 and 74; the passing time is approx. 150 ms. This order number is supplied with 24 V DC, with a permissible tolerance of 85 to 110 percent. The power consumption is approx. 4.5 W. In the input and start circuit as well as in the feedback circuit, voltage and current are 24 V DC and 50 mA. The contact load differs according to utilisation category. For AC-1, 240 V with 8 A and 2000 VA or 400 V with 5 A and 2000 VA apply. For DC-1, the switching values are 24 V with 8 A and 200 W. The contact fusing is 10 A with a quick-acting or 6 A with a slow-acting fuse. The PNOZ-3 relay of this order is handled in the specific order with shipping from Germany to the United States and other international destinations. The pull-in delay is approx. 250 ms, the drop-out delay at most 50 ms. The ambient temperature is minus 10 to plus 55 °C, the storage temperature minus 40 to plus 85 °C. Mounting on a DIN rail is specified; the mounting position is arbitrary. The thermoplastic housing made of Noryl SE 100 has IP40, the connection area IP20. The dimensions are 135 mm width, 75 mm height and 111.5 mm depth. The weight is 830 g. The front indicators are named Power, CH1 and CH2.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Pilz |
|---|---|
| Product series | PNOZ 3 |
| Manufacturer/order/ident number | 474894 |
| Device type | Safety relay |
| Supply voltage | 24 V DC; tolerance 85–110 % |
| Power consumption | approx. 4.5 W |
| Safety contacts | 5 N/O contacts |
| Auxiliary contacts | 1 N/C contact and 1 N/O contact as passing contact |
| Input and start circuit | 24 V DC, 50 mA |
| Switching capacity AC-1 | 240 V / 8 A / 2000 VA; 400 V / 5 A / 2000 VA |
| Switching values DC-1 | 24 V / 8 A / 200 W |
| Contact fusing | 10 A quick-acting or 6 A slow-acting |
| Pull-in delay | approx. 250 ms |
| Drop-out delay | max. 50 ms |
| Passing contact 73–74 | approx. 150 ms |
| Degree of protection | Housing IP40; terminal area IP20 |
| Ambient temperature | −10 to +55 °C |
| Mounting | DIN rail; any mounting position |
| Dimensions | 135 × 75 × 111.5 mm |
| Weight (reference basis not stated) | 830 g |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
Which contacts does Pilz 474894 have?
Five N/O contacts as safety contacts, one N/C contact as auxiliary contact and an additional N/O contact as passing contact.
