Product description

SEW-Eurodrive MXA81A-064-503-00 is an axis module in the modular MOVIAXIS range. The complete type number identifies the MXA81A version with one safety relay, 64 A rated output current at 8 kHz PWM and size 5. At 4 kHz PWM, rated output current is 85 A. Up to 160 A is available for short load peaks, and overload capacity is limited to 250 % for no more than one second. The module operates in the common DC link of a MOVIAXIS axis system. At 400 V mains voltage, nominal DC-link voltage is 560 V DC. A nominal DC link of 750 V DC applies with an MXR supply and regenerative module. Output voltage ranges from 0 V to the maximum mains voltage, and maximum supported output frequency is 600 Hz. The individual module controls one servo axis in the system. With one safety relay, the version meets Performance Level d according to EN ISO 13849-1 when integrated accordingly. The enclosure rating is IP10. Complete external dimensions are 150 × 400 × 210 mm in width × height × depth order. Device weight is 15.6 kg. Dimensions and weight refer to the individual axis module without shipping packaging. Type number, 64-A current stage, size 5, DC-link voltage and safety version form the exact variant data.

SEW-Eurodrive MXA81A-064-503-00 The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ.

Specifications

Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.

Manufacturer SEW-Eurodrive
Product series MOVIAXIS MXA81A
Manufacturer / order / identification number MXA81A-064-503-00
Device type Axis module for multi-axis servo systems
Size 5
Rated output current at 8 kHz PWM 64 A
Rated output current at 4 kHz PWM 85 A
Maximum output current 160 A
Rated DC bus at 400 V mains 560 V DC
Rated DC bus with MXR module 750 V DC
Output voltage 0 V up to maximum mains voltage
Overload capacity 250 % for maximum 1 s
PWM frequencies 4 kHz and 8 kHz
Safety version One safety relay
Performance Level PL d according to EN ISO 13849-1
Module role Single-axis control in the MOVIAXIS system
DC-bus system Shared DC bus
Dimensions 150 × 400 × 210 mm (W × H × D)
Weight 15.6 kg
