SICK WTB4-3P2161
€100.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
With a sensing range of 30 to 1,600 mm, SICK WTB26P-24161120A00 detects objects as a compact W26 photoelectric proximity sensor. Background suppression separates the target object from the area behind it. A PinPoint LED with visible red light and a wavelength of 635 nm serves as the light source. In the automation system, the sensor provides optical presence detection and supplies the switching signal to the downstream controller. The switching output is designed as push-pull PNP/NPN. IO-Link supplements the digital switching function with the sensor communication interface. Supply voltage ranges from 10 to 30 V DC. Current consumption without load is no more than 30 mA, while the switching frequency is 1,000 Hz. These electrical and optical characteristics are assigned directly to the complete WTB26P-24161120A00 identification number. The sensing range is set using Teach-Turn; BluePilot indicates the selected range with blue LEDs. The operating-temperature range extends from −40 °C to +60 °C. The VISTAL® plastic housing has a PMMA front screen. Electrical connection is provided by a 4-pin M12 connector. The rectangular housing meets protection ratings IP66, IP67 and IP69. This combination defines the specific sensor version within the W26 range. The full type code distinguishes it from W26 sensors with different optics, connection types or output configurations. At 24.6 mm wide, 82.5 mm high and 53.3 mm deep, the sensor remains compact. Net weight is approximately 80 g. The maximum tightening torque for the mounting screws is 1.3 Nm. Manufacturer, product range, operating principle, sensing range, light source, output, IO-Link, supply and M12 connection together define the technical identity of SICK WTB26P-24161120A00.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | SICK |
|---|---|
| Product range | W26 |
| Manufacturer/order/identification number | WTB26P-24161120A00 |
| Device type | Compact photoelectric proximity sensor |
| Operating principle | Photoelectric proximity sensor with background suppression |
| Sensing range | 30 to 1,600 mm |
| Light type | visible red light |
| Light source | PinPoint LED |
| Wavelength | 635 nm |
| Switching output | push-pull PNP/NPN |
| Communication interface | IO-Link |
| Supply voltage | 10 to 30 V DC |
| Current consumption | ≤ 30 mA without load |
| Switching frequency | 1,000 Hz |
| Connection | M12 connector, 4-pin |
| Protection rating | IP66, IP67 and IP69 |
| Dimensions | 24.6 × 82.5 × 53.3 mm (W × H × D) |
| Weight | approximately 80 g |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What sensing range and light source does SICK WTB26P-24161120A00 use?
The sensing range is 30 to 1,600 mm. The light source is a PinPoint LED with visible red light and a wavelength of 635 nm.
Which supply, interface and protection ratings apply?
Supply voltage is 10 to 30 V DC. The sensor has IO-Link, a 4-pin M12 connection and protection ratings IP66, IP67 and IP69.
What applies if an item develops a defect within 14 days?
For the condition categories “Used, removed from an installation” and “New, old stock”, the contractual 14-day right of return in the event of a defect applies. The defect must occur within 14 calendar days after delivery and be reported in text form within the same period.
In particular, the REHA tamper-evident seal must remain fully intact and our RMA approval is required before return. In an accepted case, we decide between replacement and refund. Details in Section 11 of the Terms.
Which shipping methods and delivery times are available?
The shipping method, shipping cost and estimated delivery time are confirmed for the specific order. Depending on the item, destination and urgency, we can check parcel, express or freight shipping as well as collection.
A delivery date is binding only if we expressly confirm it as binding.
Which payment terms apply?
The payment terms stated in the checkout or order confirmation apply. Depending on the order and customer, payment is made in advance or against invoice.
International deliveries and deliveries to new customers are generally made against advance payment unless we expressly confirm another payment arrangement.
Can I return an item ordered incorrectly or found incompatible?
No. There is no general B2B right of return, exchange, cancellation or withdrawal. Incorrect or duplicate orders and a lack of suitability or compatibility with the customer’s installation are not covered by the contractual 14-day right of return in the event of a defect. Details in Section 12 of the Terms.
Can I request individual pricing for several items?
You may request an individual quotation for several items or larger quantities. We then check availability and pricing for the specific requirement; there is no entitlement to a quantity discount. Open the quick enquiry.
Do you also purchase industrial spare parts?
Yes. You can offer us automation and drive components for purchase. Please provide complete type numbers, quantities, condition details and photographs where possible.
After review, we will tell you whether a purchase is possible and on which terms. Learn more about selling industrial stock.
