Siemens 1FK7063-5AF71-1TG0
€1,670.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Siemens 1FK7062-2AF71-1QA0 is a permanent-magnet synchronous servo motor from the SIMOTICS S-1FK7 Compact product series. For winding 2AF71, the data sheet states 3000 U/min rated speed, 6.0 Nm rated torque and 4.0 A rated current. Standstill torque at 100 K is 8.5 Nm. At the optimum operating point, the motor delivers 1.9 kW. The documented mechanical limits are 7200 U/min and 26 Nm. The complete order number identifies the specific mechanical and electrical version. It includes natural cooling, an AS20DQI absolute encoder with 20-bit singleturn resolution and DRIVE-CLiQ, a shaft with feather key and no holding brake. Power and signal connectors are rotatable. IP64 is the documented protection rating; IM B5, IM V1 and IM V3 are listed. The official dimension drawing for 1FK7062 with AS20DQI encoder and without holding brake states a housing length of 190 mm from the flange face. Together with the 50 mm shaft, this gives an overall length of 240 mm. Flange width and flange height are both 126 mm. The value describes the basic envelope including shaft and flange; rotatable connectors are shown without connected cables. The Siemens data sheet for the exact order number confirms a net weight of 9.1 kg. This manufacturer value expressly applies to the documented version without holding brake. Dimensions and weight are assigned to the documented encoder, shaft and brake configuration. The complete order number remains decisive for dimensional identification.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | SIMOTICS |
| Manufacturer / order / identification number | 1FK7062-2AF71-1QA0 |
| Rated power | 1.9 kW |
| Rated speed | 3000 min⁻¹ |
| Static torque | 8.5 Nm |
| Rated torque | 6.0 Nm |
| Stall current | 5.3 A |
| Rated current | 4.0 A |
| Shaft height | 63 mm |
| Holding brake | No (without holding brake) |
| Degree of protection | IP64 |
| Cooling method | Natural cooling |
| Dimensions | 240 × 126 × 126 mm (L × W × H; basic envelope incl. 50-mm shaft and flange; rotatable connectors without connected cables) |
| Weight | 9.1 kg (without holding brake) |
Related products
Go to shop
Siemens 1FK6040-6AK71-1EG0
€1,680.00
Siemens 1FK7032-2AK71-1QG0
€830.00
Siemens 1FK7032-2AK71-1QG1
€750.00
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the dimensions of Siemens 1FK7062-2AF71-1QA0?
The basic envelope is 240 × 126 × 126 mm. This includes the 190 mm housing length from the flange face, the 50 mm shaft and the 126 × 126 mm flange; connected cables are not included.
How much does Siemens 1FK7062-2AF71-1QA0 weigh?
The official Siemens data sheet states a net weight of 9.1 kg for this specific version without holding brake.
What applies if an item develops a defect within 14 days?
For the condition categories “Used, removed from an installation” and “New, old stock”, the contractual 14-day right of return in the event of a defect applies. The defect must occur within 14 calendar days after delivery and be reported in text form within the same period.
In particular, the REHA tamper-evident seal must remain fully intact and our RMA approval is required before return. In an accepted case, we decide between replacement and refund. Details in Section 11 of the Terms.
Which shipping methods and delivery times are available?
The shipping method, shipping cost and estimated delivery time are confirmed for the specific order. Depending on the item, destination and urgency, we can check parcel, express or freight shipping as well as collection.
A delivery date is binding only if we expressly confirm it as binding.
Which payment terms apply?
The payment terms stated in the checkout or order confirmation apply. Depending on the order and customer, payment is made in advance or against invoice.
International deliveries and deliveries to new customers are generally made against advance payment unless we expressly confirm another payment arrangement.
Can I return an item ordered incorrectly or found incompatible?
No. There is no general B2B right of return, exchange, cancellation or withdrawal. Incorrect or duplicate orders and a lack of suitability or compatibility with the customer’s installation are not covered by the contractual 14-day right of return in the event of a defect. Details in Section 12 of the Terms.
Can I request individual pricing for several items?
You may request an individual quotation for several items or larger quantities. We then check availability and pricing for the specific requirement; there is no entitlement to a quantity discount. Open the quick enquiry.
Do you also purchase industrial spare parts?
Yes. You can offer us automation and drive components for purchase. Please provide complete type numbers, quantities, condition details and photographs where possible.
After review, we will tell you whether a purchase is possible and on which terms. Learn more about selling industrial stock.
