Siemens 1FT5062-1AC71-4AA0
€1,020.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Siemens 1FT5044-0AH01-1 is a naturally cooled AC-VSA servo motor from the 1FT5 product series. The specific version is described for a 210 V DC link. Rated torque is 2.0 Nm at 100 K and rated speed is 4500 rpm. IP64 is the documented degree of protection. Feedback comprises a tachogenerator and a rotor-position encoder. The electrical version has separate power and signal connectors. IM B5 is the documented construction, with IM V1 and IM V3 also listed as mounting positions. Self-cooling and natural convection describe the cooling concept of the motor variant. The complete order number assigns DC link, torque, speed, feedback, connections, protection and construction to the same version. The official Siemens dimension sheet for frame size 1FT5044 states an installation length of 190 mm. The shaft projects by 30 mm, the motor cross-section measures a nominal 92 mm and the connector structure reaches an overall height of 123.5 mm. This results in a motor envelope of 220 × 92 × 123.5 mm. The sheet also states a shaft height of 48 mm, a centering diameter of 80 mm and a shaft diameter of 14 mm. The dimensions include shaft and connector structure, but no connected cables. The dimension drawing shows the basic version with an axially depicted shaft and a top-mounted connector structure. Siemens states a weight of 4.2 kg without brake and 4.5 kg with brake for the frame size. Because the available product identification does not reliably distinguish the brake version, weight is conservatively stated as approx. 4.5 kg. The value is explicitly marked as a product-specific estimate and replaces the previous non-value.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | 1FT5 |
| Manufacturer / order / identification number | 1FT5044-0AH01-1 |
| Device type | AC-VSA motor |
| Motor concept | AC feed motor |
| DC-link voltage | 210 V DC |
| Rated torque (100 K) | 2.0 Nm |
| Rated speed | 4500 rpm |
| Degree of protection | IP64 |
| Mounting arrangement | IM B5 (IM V1, IM V3) |
| Feedback | Tachogenerator and rotor-position encoder |
| Connections | Power and signal connectors |
| Cooling concept | Self-cooled |
| Cooling method | Natural convection |
| Shaft height | 48 mm |
| Centering diameter | 80 mm |
| Shaft diameter | 14 mm |
| Dimensions | 220 × 92 × 123.5 mm (L × W × H; motor envelope incl. 30-mm shaft and connector structure; installation length 190 mm) |
| Weight | approx. 4.5 kg |
Related products
Go to shop
Siemens 1FT5066-0AF01-2
€490.00
Siemens 1FT6034-4AK71-4EG1
€2,010.00
Siemens 1FT6044-4AK71-4AB6
€1,500.00
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the dimensions and weight of Siemens 1FT5044-0AH01-1?
The motor envelope is 220 × 92 × 123.5 mm including a 30 mm shaft extension at a 190 mm installation length. Weight is conservatively stated as approx. 4.5 kg.
Why is the weight marked as an estimate?
The Siemens sheet states 4.2 kg without brake and 4.5 kg with brake. Because the available data does not reliably distinguish the brake version, the higher value is conservatively stated as approx. 4.5 kg.
What applies if an item develops a defect within 14 days?
For the condition categories “Used, removed from an installation” and “New, old stock”, the contractual 14-day right of return in the event of a defect applies. The defect must occur within 14 calendar days after delivery and be reported in text form within the same period.
In particular, the REHA tamper-evident seal must remain fully intact and our RMA approval is required before return. In an accepted case, we decide between replacement and refund. Details in Section 11 of the Terms.
Which shipping methods and delivery times are available?
The shipping method, shipping cost and estimated delivery time are confirmed for the specific order. Depending on the item, destination and urgency, we can check parcel, express or freight shipping as well as collection.
A delivery date is binding only if we expressly confirm it as binding.
Which payment terms apply?
The payment terms stated in the checkout or order confirmation apply. Depending on the order and customer, payment is made in advance or against invoice.
International deliveries and deliveries to new customers are generally made against advance payment unless we expressly confirm another payment arrangement.
Can I return an item ordered incorrectly or found incompatible?
No. There is no general B2B right of return, exchange, cancellation or withdrawal. Incorrect or duplicate orders and a lack of suitability or compatibility with the customer’s installation are not covered by the contractual 14-day right of return in the event of a defect. Details in Section 12 of the Terms.
Can I request individual pricing for several items?
You may request an individual quotation for several items or larger quantities. We then check availability and pricing for the specific requirement; there is no entitlement to a quantity discount. Open the quick enquiry.
Do you also purchase industrial spare parts?
Yes. You can offer us automation and drive components for purchase. Please provide complete type numbers, quantities, condition details and photographs where possible.
After review, we will tell you whether a purchase is possible and on which terms. Learn more about selling industrial stock.
