Siemens 1FT5074-1AF71-1AA0
€2,090.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Siemens 1FT5074-0AK01-2 is a permanent-magnet AC servo motor from the 1FT5 series. The specified DC-link voltage is 210 V DC. Torque is 18 Nm at 100 K and rated speed is 6000 U/min. The motor uses natural cooling and has protection class IP64. Mechanical construction is IM B5; mounting positions IM V1 and IM V3 are also documented. A tachogenerator and rotor-position encoder are integrated for feedback. Power and signals are connected through the terminal box and signal connector. The straight shaft has a diameter of 24 mm and the mounting-flange centering diameter is 130 mm. The complete product contour measures 380 mm in length, 160 mm in width and 230 mm in height. The terminal box is included in this outside envelope. Complete outside dimensions are therefore 380 × 160 × 230 mm. Documented item weight is 18.4 kg. The complete designation 1FT5074-0AK01-2 distinguishes this 210-V version with 6000 U/min, terminal box and signal connector from 1FT5074 variants with a different DC-link voltage or connection form. Fixed buyer data therefore cover electrical assignment, torque, speed, cooling, protection class, feedback system, mounting form, shaft size, outside envelope and weight. The stated height fully includes the raised terminal-box contour.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | 1FT5 |
| Manufacturer / order / identification number | 1FT5074-0AK01-2 |
| Device type | AC servo motor |
| Motor type | Permanent-magnet synchronous servo motor |
| Motor function | Feed drive motor |
| DC-link voltage | 210 V DC |
| Torque | 18 Nm at 100 K |
| Rated speed | 6000 U/min |
| Protection rating | IP64 |
| Cooling | Natural cooling |
| Feedback | Tachogenerator and rotor-position encoder |
| Mounting arrangement | IM B5, also IM V1 and IM V3 |
| Connection type | Terminal box and signal connector |
| Dimensions | 380 × 160 × 230 mm (L × W × H; including terminal box) |
| Weight | 18.4 kg |
