Siemens 6GK7443-1EX11-0XE0
€770.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Siemens 6AG1312-5BD01-2AB0 is based on module 6ES7 312-5BD01-0AB0. Two high-speed counters operate at up to 10 kHz; supply voltage is 24 V DC. A SIMATIC Micro Memory Card serves as the storage medium, and the operating-temperature range extends from −25 to +60 °C. Siemens 6AG1312-5BD01-2AB0 is a SIPLUS version of the compact SIMATIC-S7-300 CPU-312C. It is based on standard module 6ES7 312-5BD01-0AB0 and has an extended ambient-temperature range from −25 °C to +60 °C. The CPU has 16 kB working memory and uses a SIMATIC Micro Memory Card as load memory. Ten digital inputs and six digital outputs are integrated directly. Two high-speed counters operate at up to 10 kHz and handle simple counting and frequency-measurement tasks without a separate function module. The integrated power supply is rated at DC 24 V; a 40-pin front connector is used for the built-in inputs and outputs. Siemens assigns firmware V2.0.12 and STEP 7 from V5.2 SP2 to the underlying CPU 312C 6ES7 312-5BD01-0AB0. The SIPLUS order number is also listed as a CPU module for Class I, Division 2, Groups A, B, C and D. The compact design does not identify a different CPU variant solely from similar connection data. Installation, wiring and commissioning are carried out by qualified personnel in accordance with the Siemens documentation. The exact module identity preserves the integrated I/O and counter structure of the CPU 312C.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product family | SIPLUS SIMATIC S7-300 |
| Manufacturer/order/identification number | 6AG1312-5BD01-2AB0 |
| Device type | Compact CPU 312C |
| Base module | 6ES7 312-5BD01-0AB0 |
| Working memory | 16 kB |
| Digital inputs | 10 integrated DI |
| Digital outputs | 6 integrated DO |
| Counter channels | 2 high-speed counters |
| Counter frequency | maximum 10 kHz |
| Supply voltage | DC 24 V, integrated |
| Connection | 40-pin front connector |
| Operating temperature | −25 °C to +60 °C |
| Load memory | SIMATIC Micro Memory Card (MMC) |
| Base module firmware assignment | V2.0.12 |
| Base module configuration software | STEP 7 from V5.2 SP2 |
| Approval | Class I, Division 2, Groups A, B, C and D |
| Dimensions | 80 × 125 × 115 mm (W × H × D; front cover closed) |
| Weight | ca. 0.45 kg |
