Siemens 6AG2512-1SK01-1AB0
Price on request
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Documented identifiers and values: 6AG2512-1DM03-4AB0; 6ES7512-1DM03-0AB0; 25; 40; 70; 415 g. The central processing unit is based on Siemens 6ES7512-1DM03-0AB0 and combines a compact ET-200SP design with high-performance S7-1500 technology. A SIMATIC Memory Card is required and can be used as removable load memory with a capacity of up to 32 GB. As a PROFINET IO controller, the CPU can connect up to 128 IO devices. Power is supplied at 24 V DC within the specified range from 19.2 to 28.8 V DC. Conformal Coating and the specified operating temperature range from -40 to +70 °C support applications with increased climatic requirements; Siemens specifies ST1/2 up to +85 °C for ten minutes. Maximum current consumption is 0.7 A and typical power loss is 6.5 W. Siemens 6AG2512-1DM03-4AB0 is a SIPLUS ET 200SP CPU 1512SP-1 PN RAIL for distributed control tasks and demanding railway environments. The first interface supports PROFINET IRT and provides an integrated 3-port switch; port 1 and 2 are supplied through a suitable ET 200SP BusAdapter. It provides 400 KB of work memory for the user program and a further 2 MB for data. The typical execution time for bit operations is 25 ns. Siemens documents overall dimensions of 100 × 117 × 75 mm for this exact CPU. These mechanical data support planning for cabinet space, handling, storage and transport while the electrical, network and configuration characteristics remain separate checks for the hardware assignment.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product range | SIPLUS ET 200SP |
| Manufacturer/order/identification number | 6AG2512-1DM03-4AB0 |
| Device type | CPU 1512SP-1 PN RAIL |
| Base unit | 6ES7512-1DM03-0AB0 |
| Protective coating | Conformal Coating |
| Operating temperature | -40 to +70 °C |
| Short-term temperature | ST1/2 up to +85 °C for 10 minutes |
| Program memory | 400 KB |
| Data memory | 2 MB |
| Removable load memory | SIMATIC Memory Card up to 32 GB |
| Bit execution time | typ. 25 ns |
| Supply voltage | 24 V DC, permissible range 19.2 to 28.8 V DC |
| Maximum current consumption | 0.7 A |
| Typical power loss | 6.5 W |
| PROFINET interface | PROFINET IRT |
| PROFINET ports | 3 ports with integrated switch |
| BusAdapter | Required for port 1 and 2 |
| Dimensions | 100 × 117 × 75 mm (W × H × D) |
| Weight | approx. 415 g |
Related products
Go to shop
Siemens 6AG2512-1SK01-4AB0
Price on request
Siemens 6AG2512-1DM03-1AB0
Price on request
Siemens 6AG2193-6BP00-4BA0
€80.00
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the dimensions and weight of Siemens 6AG2512-1DM03-4AB0?
The CPU measures 100 × 117 × 75 mm in width × height × depth order and weighs approximately 415 g according to the Siemens technical data sheet.
Which memory and interface features are documented?
The documented features are 400 KB program memory, 2 MB data memory and PROFINET IRT with an integrated 3-port switch.
