Siemens 6AV2 123-2JB03-0AX0
€1,105.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Siemens 6AV2123-2DB03-0AX0 identifies the SIMATIC HMI KTP400 Basic in the 2nd generation of Basic Panels. The operator device combines key and touch operation. Its 4.3-inch TFT widescreen with LED backlight has a visible area of 95 × 53.9 mm, a resolution of 480 × 272 pixels and displays 65.536 colours. The touchscreen is analog-resistive and 4 function keys are also provided. PROFINET is documented for communication. Power is supplied at 24 V DC within the permissible range of 19.2–28.8 V DC. Rated current consumption is 125 mA. WinCC Basic V13 or STEP 7 Basic V13 are specified as the engineering basis. The mechanical data belongs to this exactly identified panel version. The housing front is 140 mm wide and 116 mm high. Documented overall depth is 34.9 mm. Complete external dimensions are therefore 140 × 116 × 34.9 mm in width × height × depth order. Weight without packaging is 360 g. Portrait and landscape orientations are supported. Device designation, operating concept, display data, function keys, communication, supply, engineering and mechanical data are combined in one variant-specific record. The complete manufacturer/order/identification number 6AV2123-2DB03-0AX0 distinguishes this KTP400 Basic from other sizes and interface versions in the SIMATIC HMI range. Installation is possible in portrait or landscape orientation. Front-side protection reaches IP65 or Type 4X/12; rear-side protection is IP20. Maximum installation altitude is 2,000 m and the permissible inclination angle is 35°.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | SIMATIC HMI Basic Panels, 2nd generation |
| Manufacturer / order / identification number | 6AV2123-2DB03-0AX0 |
| Device type | KTP400 Basic |
| Operating concept | Key and touch operation |
| Display | 4.3-inch TFT widescreen with LED backlight |
| Display area | 95 × 53.9 mm |
| Resolution | 480 × 272 pixels |
| Colour display | 65.536 colours |
| Touchscreen | Analog-resistive |
| Function keys | 4 |
| Communication | PROFINET |
| Power supply | 24 V DC, permissible 19.2–28.8 V DC |
| Rated current consumption | 125 mA |
| Engineering | from WinCC Basic V13 / STEP 7 Basic V13 |
| Mounting | Portrait and landscape orientation supported |
| Dimensions | 140 × 116 × 34.9 mm (W × H × D) |
| Weight | 360 g (without packaging) |
