Siemens 6ES7 414-3EM07-0AB0
Price on request
Shipping information
Do you require same-day delivery or express shipping with a defined delivery time for this item?
Please contact us!
Product description
The Siemens 6ES7515-2AN03-0AB0 is a powerful central processing unit from the SIMATIC-S7-1500 family for demanding machine, manufacturing and process automation. As a CPU 1515-2 PN, it combines 1 MB integrated program memory with 4.5 MB data memory and 6 ns bit performance. This makes it suitable for extensive control programs, fast logic processing and networked automation tasks with high requirements for diagnostics, communication and system availability. Two separate PROFINET interfaces are available for communication. The first supports PROFINET IRT and includes an integrated 2-Port-Switch; the second operates with PROFINET RT. The CPU is supplied with 24 V DC. Rated current consumption is 0.65 A, with a maximum of 1.03 A. It feeds up to 12 W into the backplane bus and draws 6.2 W from it under balanced conditions. A 6.1 cm display, eight control keys and two mode buttons support commissioning, diagnostics and service directly on the device. A SIMATIC Memory Card is required for operation. The 6ES7515-2AN03-0AB0 is suitable as a type-identical replacement in existing S7-1500 stations and for modernisation projects that retain the existing PROFINET and TIA Portal architecture. Before replacement, hardware revision, firmware, TIA Portal project version, memory card, device configuration and network parameters must be checked carefully. The complete order number 6ES7515-2AN03-0AB0 is decisive because neighbouring CPU variants may differ in memory, performance and interfaces. The documented net weight of 0.513 kg also supports spare-parts and logistics planning for maintenance, series machines and production-critical control systems. This reduces downtime and enables structured preparation for planned CPU replacement.
Specifications
| Manufacturer | Siemens |
|---|---|
| Product series | SIMATIC S7-1500 |
| Manufacturer / order / identification number | 6ES7515-2AN03-0AB0 |
| Device type | CPU 1515-2 PN central processing unit |
| Program work memory | 1 MB |
| Data work memory | 4.5 MB |
| Bit performance | 6 ns |
| Interface 1 | PROFINET IRT with 2-Port-Switch |
| Interface 2 | PROFINET RT |
| Supply voltage | 24 V DC |
| Rated current consumption | 0.65 A |
| Maximum current consumption | 1.03 A |
| Backplane bus feed power | 12 W |
| Backplane bus power consumption | 6.2 W |
| Display diagonal | 6.1 cm |
| Control keys | 8 |
| Mode buttons | 2 |
| Memory card | SIMATIC Memory Card required |
| Net weight | 0.513 kg |
Related products
Go to shop
Siemens 6ES7416-5HS06-0AB0
Price on request
Siemens 6ES7536-1MF00-0AB0
Price on request
Siemens 6ES7 155-6AU01-0CN0
€380.00
Machine downtime?
Faster delivery
Is your machine down and do you require particularly fast delivery? Tell us directly. We will do everything possible to provide a quotation with the fastest available delivery and find a solution that matches your schedule.
Our highest priority is to keep your production processes running. Rely on our expertise and flexible service to minimise machine downtime effectively.
Contact us now!Product safety
Manufacturer / EU responsible person
Which memory and network resources does the CPU 1515-2 PN provide?
The CPU has 1 MB program memory, 4.5 MB data memory, PROFINET IRT with 2-Port-Switch and a second PROFINET RT interface.
What must be checked when replacing the 6ES7515-2AN03-0AB0?
Hardware revision, firmware, TIA Portal project version, SIMATIC Memory Card, device configuration and network parameters must be compared with the existing system.
Is there a guarantee?
Yes, we provide a 14-day functional guarantee for used items. This means the component must be operational when received.
Please note that the guarantee only applies when the warranty seal is undamaged.
If a defect occurs within 14 calendar days, please contact us in writing. Subject to availability, we will provide a replacement or refund the full purchase price after return.
Further details are provided in the terms and conditions supplied with your quotation.
How quickly do you dispatch and which shipping options are available?
We generally dispatch immediately - in many cases on the same working day. For particularly urgent requirements or machine downtime, we find a suitable solution as quickly as possible and provide a specific delivery window on request.
Express shipping or collection from our premises is also possible, depending on the situation. State your requirements during the ordering process or contact us directly.
We ship worldwide and work with reliable shipping partners, from parcel services to freight forwarding. Freight shipments normally require some preparation so the goods arrive safely and undamaged.
Which payment methods are available?
Payment is normally made by bank transfer against invoice. Payment is due within 10 calendar days of receiving the goods.
As a rule, we offer purchase on account for all customers. In individual cases, such as new customers or particularly high-value components, we may agree advance payment. This decision is made individually and communicated transparently.
Can we return items if they were ordered incorrectly?
Because we sell exclusively to business customers (B2B), there is no general right of return and no consumer right of withdrawal.
Please note that returns of functioning goods are generally excluded. In justified exceptional cases, we can assess an individual solution, but this is not the standard procedure.
Is there a discount when ordering several items?
For larger order quantities or several items of one type, we can offer individual discounts.
Simply send us a quick enquiry - we check availability and will gladly prepare a tailored quotation with quantity pricing.
Do you also purchase industrial spare parts?
Yes, we also purchase automation components, such as frequency inverters, PLC assemblies, panels, servo motors and CPUs. Components from Siemens, Lenze, Schneider Electric, Control Techniques or Heidenhain are especially sought after, and other brands are also possible.
The process is straightforward: email us an inventory list or overview photos at info@reha-industriekomponenten.de. We calculate a market-based purchase price and send you an offer.
