Siemens 6FC5357-0BB11-0AE0
€410.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Siemens 6FC5357-0BA20-0AE0 identifies a Numerical Control Unit NCU 572 for the SINUMERIK 840D CNC system. As the central processing module, it combines an NC CPU and a PLC CPU. It executes the NC program and maintains communication with drives, operator components and machine peripherals. The standard configuration of NCU 572 and NCU 573 comprises two channels and eight axes. Usable functional scope depends on the hardware version, installed system software and enabled options. The NCU provides interface X101 with MPI at 1.5 MBaud for the operator panel front. PROFIBUS DP is connected at X102, while X122 serves as the programming-device interface with MPI at 187.5 kBaud. The SIMATIC I/O bus is available through X111. Handwheels, touch probes and NC I/O connect through X121; X130A provides the link to SIMODRIVE 611D. Slot X173 accepts the PCMCIA Memory Card. Status and fault LEDs, a 7-segment display and switches for NCK, PLC, reset and NMI support commissioning and diagnostics. Complete external dimensions of NCU 572 are 50 mm wide, 316 mm high and 115 mm deep. Device weight is 0.75 kg. Inside the intended NCU box the system provides IP20 protection; without the box it is IP00. Hardware version, system software and enabled options determine the functional scope of the specific module. Complete order number 6FC5357-0BA20-0AE0 identifies this NCU-572 version within the NCU 571 and NCU 573 product range.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product range | SINUMERIK 840D |
| Manufacturer / order / identification number | 6FC5357-0BA20-0AE0 |
| Device type | Numerical Control Unit NCU 572 |
| Control function | combined NC CPU and PLC CPU |
| Standard configuration | 2 channels and 8 axes for NCU 572/573 |
| Operator panel front interface | X101, MPI 1.5 MBaud, electrically isolated |
| PROFIBUS DP | interface X102 |
| SIMATIC I/O bus | X111, P/C bus |
| Programming device interface | X122, MPI 187.5 kBaud, non-isolated |
| NC I/O connection | X121 for handwheels, touch probes and NC I/O via cable distributor |
| Drive interface | X130A for SIMODRIVE 611D |
| Memory card slot | PCMCIA slot X173 |
| Diagnostics | status and fault LEDs plus 7-segment display |
| Commissioning controls | switches for NCK and PLC plus reset/NMI |
| Ingress protection | IP20 with NCU box; IP00 without NCU box |
| Protection class | Class I with protective conductor according to EN 61800-5-1 |
| Cooling | open-circuit ventilation in the NCU system |
| Dimensions | 50 × 316 × 115 mm (W × H × D) |
| Weight | 0.75 kg |
