Siemens 6SE6420-2AD24-0BA1
€340.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Siemens 6SE6420-2UD13-7AA1 is a frequency converter from the MICROMASTER 420 series. The exact version belongs to frame size FSA and operates on a three-phase 380 to 480 V mains supply with a tolerance of ±10 %. Documented mains frequency ranges from 47 to 63 Hz. Under high overload, rated power is 0.37 kW or 0.50 hp. Siemens specifies a rated input current of 2.20 A and a rated output current of 1.20 A. Pulse frequency is 4,000 Hz. With U/f control, output frequency ranges from 0 to 650 Hz; the data sheet lists 550 Hz as the productive limit. Overload capability is documented as 150 % for 60 s, followed by 100 % for 240 s. Signal equipment comprises three digital inputs, one relay output, one analog input and one analog output. The device uses fan cooling and has IP20 protection or UL Open Type construction. Its operating temperature range is -10 to 50 °C. Siemens assigns order number 6SE6420-2UD13-7AA1 to frame size FSA. Complete external dimensions are 73 × 173 × 149 mm in width × height × depth order. Documented net weight is 1.00 kg. Dimensions and weight refer to the device rather than shipping packaging. Order number, supply class, power and current values, signal equipment and frame size identify the exact version within the MICROMASTER-420 family. The specification table presents these technical buyer data separately and ends with the canonical Dimensions and Weight rows. This keeps axis order and measurement scope explicit in the product record.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | MICROMASTER 420 |
| Manufacturer/order/identification number | 6SE6420-2UD13-7AA1 |
| Device type | Frequency inverter |
| Mains connection | 3 AC 380–480 V, ±10 % |
| Mains frequency | 47–63 Hz |
| Rated power, high overload | 0.37 kW / 0.50 hp |
| Rated input current | 2.20 A |
| Rated output current | 1.20 A |
| Pulse frequency | 4,000 Hz |
| Output frequency | 0–650 Hz with U/f control; productive limit 550 Hz |
| Overload capability | 150 % for 60 s, followed by 100 % for 240 s |
| Inputs and outputs | 3 digital inputs, 1 relay output, 1 analog input, 1 analog output |
| Cooling | Fan |
| Degree of protection | IP20 / UL Open Type |
| Operating temperature | -10 to 50 °C |
| Dimensions | 73 × 173 × 149 mm (W × H × D) |
| Weight | 1.00 kg |
