Bosch Rexroth VDP16.2AKN-G4-NN-NN
Price on request
Availability is checked individually.
Product condition:
Used, removed from an installation
The item comes from dismantled equipment. We have not carried out an electrical inspection or a comprehensive operational check. Signs of age, use, installation or removal may be present. 14-day right of return in the event of a defect. See Terms and Conditions
- The estimated delivery time will be confirmed for the specific order.
- Urgent? Faster options such as direct or express shipping are often possible. Please state your required date when you request a quote or order.
Do you have any questions?
Personal service
We are happy to help with processing, shipping or individual quotations. Simply contact us:
Online and available Currently unavailable
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
With its 12-inch display and touch operation, the Bosch Rexroth VDP16.2AKN-G4-NN-NN belongs to the IndraControl VDP series. It is configured as a separate operating and display terminal for connection to a control cabinet PC. The variant has a G4 display interface; CDI is specified as the operator panel interface. The rectangular housing is 360 mm wide, 300 mm high and 70 mm deep. The weight is 4.18 kg. Mounting is carried out via mounting brackets on a flat, mechanically load-bearing surface. For installation, the position of the connections and the space for cable routing must be taken into account in addition to the housing dimensions. The permissible temperature range during operation extends from +5 to +45 °C. For storage, a range of −20 to +60 °C is specified. The maximum installation altitude is 2000 m above sea level. The specified vibration frequency range lies between 10 and 150 Hz. The switch-off time of the display backlight is adjustable. Four status LEDs indicate power supply, UPS, hard disk activity and temperature messages. For an order of this VDP16.2AKN-G4-NN-NN, shipping from Germany to the United States and other international destinations is arranged for that specific order. For the assignment to an existing operator station configuration, the complete type designation is decisive, including the interface section G4 and the two final NN blocks. The panel must therefore be matched on the basis of its complete marking, the connections and the existing installation situation. The LCD backlight has a stated operating duration of 40.000 hours until its brightness is halved. Direct sunlight and UV light can impair the readability of the display. The touch operation and the status indicators are components of the operating front.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Bosch Rexroth |
|---|---|
| Product series | IndraControl VDP |
| Manufacturer/order/ident number | VDP16.2AKN-G4-NN-NN |
| Device type | Operating and display terminal |
| Operation | Touchscreen |
| Display diagonal | 12 inches |
| Operator panel interface | CDI |
| Display interface | G4 |
| Operating temperature | +5 to +45 °C |
| Storage temperature | −20 to +60 °C |
| Maximum installation altitude | 2000 m above sea level |
| Vibration frequency range | 10–150 Hz |
| Display backlight | Switch-off time adjustable |
| Diagnostic indicators | Four status LEDs |
| Mounting | Via mounting brackets on a flat, mechanically load-bearing surface |
| Dimensions | 360 × 300 × 70 mm (W × H × D) |
| Weight | 4.18 kg |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
Which interfaces does the VDP16.2AKN-G4-NN-NN have?
The version has a G4 display interface and a CDI operator panel interface.
