Product description
Two lines of 20 characters each form the operator display of the Control Techniques EMC-OIT-3165-A. The Operator Interface Terminal belongs to the OIT-3165 range and combines a backlit LCD with a membrane keypad. The display uses a 5 × 7 dot matrix; each character is 4.8 mm high. A total of 24 programmable keys are arranged in 3 rows. Replaceable slide-in legends provide customized key labels, while an internal audio transducer confirms key operation. The viewing angle is approximately 90 degrees. The supply voltage ranges from 12 to 30 V DC. Typical power consumption is 2.5 W. The serial interface is configurable as RS-232, RS-422 or RS-485. Configurable transmission rates range from 300 to 19.200 baud. The terminal contains 128K × 8 Flash PROM for firmware, protocol and configuration data; this memory requires no battery. The specified membrane-key lifespan is 3 million operations. Wiring uses an external power plug and shielded RJ-45 communication connectors. The aluminum enclosure uses panel mounting. With the gasket installed, the front meets the NEMA 4/12 rating. The permitted operating-temperature range is 0 to +50 °C, while storage temperature is −20 to +70 °C. The enclosure is 152.4 mm wide, 101.6 mm high and 45 mm deep. The documented net weight of this OIT-3165 version is 0.45 kg. OITware-200 is used for configuration; protocol and project data are stored in the internal Flash memory.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Control Techniques |
|---|---|
| Product range | OIT-3165 |
| Manufacturer/order/identification number | EMC-OIT-3165-A |
| Device type | Operator Interface Terminal |
| Display | backlit LCD, 5 × 7 dot matrix |
| Display capacity | 2 lines with 20 characters each; character height 4.8 mm |
| Input voltage | 12–30 V DC |
| Power consumption | 2.5 W typical |
| Serial interface | RS-232, RS-422 or RS-485 |
| Baud rates | 300, 600, 1.200, 2.400, 4.800, 9.600 or 19.200 baud |
| Keypad | membrane keypad with customizable labels |
| Programmable keys | 24, arranged in 3 rows |
| Key lifespan | 3 million operations |
| Memory | 128K × 8 Flash PROM for firmware, protocol and configuration; no battery |
| Enclosure and mounting | aluminum; panel mounting; NEMA 4/12 with installed gasket |
| Operating temperature | 0 to +50 °C |
| Storage temperature | −20 to +70 °C |
| Dimensions | 152.4 × 101.6 × 45 mm (W × H × D) |
| Weight | 0.45 kg net weight |
