Product description
The Lenze EPM-H310 is a text operator panel from the EPM-H300 product series. It provides compact indication and input at machine and plant controls belonging to this device family. The integrated LCD text display presents 2 × 20 characters. Its visible display area measures 73.5 × 11.5 mm. Individual characters use a 5 × 7 dot matrix and measure 3.2 × 5.5 mm. A total of 48 kB program memory is available for the application. Supply voltage is 24 V DC, with a documented operating range from 18 to 32 V DC. Communication with the automation system uses a CAN fieldbus connection. Up to 63 nodes are specified for a corresponding fieldbus network. Service and transfer tasks use the ASP8 service interface via RS-232. A real-time clock is not integrated in this version. The complete EPM-H310 type number identifies the panel within the EPM-H300 series. A panel cutout of 157 × 77 mm is documented for installation in a cabinet door, control desk or front panel. Overall dimensions of the individual operator panel are 166 × 86 × 41 mm. The Lenze catalogue states a device weight of 0.5 kg. These mechanical values refer to the device itself and exclude additional packaging or separately fitted connection equipment. For replacement and installation, relevant characteristics include the exact type number, supply, CAN connection, service interface, display format, enclosure size and panel cutout. Similar operator panels in the series can differ in display, memory, interfaces and front dimensions.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Lenze |
|---|---|
| Product series | Lenze EPM-H300 |
| Manufacturer/order/identification number | EPM-H310 |
| Device type | Text operator panel |
| Display type | LCD text display |
| Display area | 73.5 × 11.5 mm |
| Display layout | 2 × 20 characters |
| Character matrix | 5 × 7 dots |
| Character size | 3.2 × 5.5 mm |
| Program memory | 48 kB |
| Supply voltage | 24 V DC, range 18 to 32 V DC |
| Communication | CAN fieldbus |
| Fieldbus participants | up to 63 |
| Service interface | ASP8 via RS-232 |
| Real-time clock | not integrated |
| Panel cutout | 157 × 77 mm |
| Dimensions | 166 × 86 × 41 mm |
| Weight | 0.5 kg |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
What are the dimensions and weight of the Lenze EPM-H310?
The operator panel measures 166 × 86 × 41 mm. Its stated device weight is 0.5 kg, and the panel cutout measures 157 × 77 mm.
Which display and interfaces does the EPM-H310 have?
The device has an LCD text display with 2 × 20 characters, CAN fieldbus and an ASP8 service interface via RS-232.
