Fanuc A06B-6088-H215
€1,220.00
excl. VAT
Product condition:
Used, removed from an installation
The item comes from dismantled equipment. We have not carried out an electrical inspection or a comprehensive operational check. Signs of age, use, installation or removal may be present. 14-day right of return in the event of a defect. See Terms and Conditions
- In stock · Ships in approx. 1–2 business days · Express shipping on request
- Urgent? Faster options such as direct or express shipping are often possible. Please state your required date when you request a quote or order.
Do you have any questions?
Personal service
We are happy to help with processing, shipping or individual quotations. Simply contact us:
Online and available Currently unavailable
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
With an output power of 17.5 kW, the Fanuc A06B-6088-H215 belongs to the SPM-15 size of the ALPHA spindle amplifiers. The module forms the electronic power section of a spindle drive and has the type-1 interface of this series. The connections for the motor bear the designations U, V and W. In the lower housing area, these power connections are spatially separated from the signal connectors arranged one above the other on the front. There, the slots are labelled with JX4, JX1A, JX1B, JY1, JA7B, JA7A and JY2, among others. Above these connectors are the connection groups CX1A/CX1B and CX2A/CX2B. For AC IN/OUT, 200 to 240 V alternating voltage at 50/60 Hz is specified, for DC IN/OUT a direct voltage of 24 V. These auxiliary voltage connections are to be distinguished from the motor connections at the lower end of the module. In a specific quotation for the spindle amplifier with shipping from Germany to the United States and other international destinations, the identifier A06B-6088-H215 stands for the ALPHA module SPM-15. For heat dissipation, the assembly has both internal and external fans and an external heat sink. The modular design thus combines the electronics in the front housing area with the rear cooling arrangement. The two-digit seven-segment LED display on the front shows the amplifier status. Its labelling distinguishes READY, NOT READY and alarm codes; PIL, ALM and ERR are also listed. The module width is 150 mm. For spatial classification, the overall external dimensions are estimated at approx. 150 × 400 × 300 mm in width, height and depth. The likewise estimated weight is approx. 10 kg.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Fanuc |
|---|---|
| Product series | ALPHA SPM-15 |
| Manufacturer/order/ident number | A06B-6088-H215 |
| Device type | Spindle amplifier module |
| Output power | 17.5 kW |
| Interface | Type 1 |
| Cooling method | Internal and external fan, external heat sink |
| Status display | Two-digit seven-segment LED display |
| Auxiliary voltage AC IN/OUT | 200–240 V AC |
| Frequency AC IN/OUT | 50/60 Hz |
| Auxiliary voltage DC IN/OUT | 24 V DC |
| Motor connections | U, V, W |
| Dimensions | approx. 150 × 400 × 300 mm |
| Weight | approx. 10 kg |
