Heidenhain 605379-91
€660.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Heidenhain 260 520 01 is the identification number of the BC 110 B visual display unit within TNC 407, TNC 415 B and TNC 425 CNC systems. The unit is a 14-inch colour monitor and provides the visual operator interface. Computing, PLC and axis functions remain in the connected logic and expansion modules. Video signals reach the monitor through the cable from the logic unit, while a ribbon cable connects the softkeys to the TNC keyboard unit. In this BC-110-B version, the built-in fan draws its supply internally from the visual display unit. The technical manual specifies complete dimensions of 400 mm width, 320 mm height and a maximum depth of 275 mm. The associated front-panel opening measures 372 × 292 mm. Depending on the mains version, documented input ranges are 85 to 132 V or 170 to 264 V at 50 to 60 Hz; maximum power consumption is 70 W. Manufacturer-specified weight is 11 kg. Rear connections serve the logic unit, keyboard unit and mains supply. A separate test button produces a bright rectangular field when the unit is powered and helps distinguish a display fault from a graphics-board problem. The full identification number 260 520 01 separates this version from the BC 110 family and later BF display variants.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Heidenhain |
|---|---|
| Product series | BC 110 B |
| Manufacturer/order/identification number | 260 520 01 |
| Device type | Visual display unit |
| Display type | Colour monitor |
| Display size | 14 inches |
| Operator function | Softkeys |
| Interface connection | Cables to the logic unit and TNC keyboard |
| Fan supply | Internal from the VDU supply |
| Fan supply voltage | +18 to +28 V DC |
| Fan power consumption | 5 W at +24 V DC |
| Fan supply connector | X3 |
| Test output | X4, do not connect externally |
| Diagnostic function | Rear test button for a bright test field |
| Version status | BC 110 B since 11/1990 |
| Dimensions | 400 × 320 × max. 275 mm (W × H × D) |
| Weight | 11 kg |
