Product description

Heidenhain 216750-BF is a sealed incremental linear encoder from the LS 703 series for direct measurement on linear axes of CNC machine tools and machining centres. The 216750-BF has a measuring length of 720 mm and an accuracy class of ±5.0 μm, supporting precise position feedback for milling, turning and grinding applications. The large-profile aluminium housing has an overall length of 870 mm. Circumferential sealing lips protect the glass scale and scanning carriage against chips, coolant spray and dust, while the IP 53 rating supports use under typical machine-tool conditions. The glass scale has a 20 μm graduation period and generates sinusoidal current signals with an output level of approximately ~11 μApp for compatible Heidenhain evaluation electronics and CNC controls. A single reference mark is located at 360 mm, the centre of the measuring length, enabling a reproducible reference run after the machine is switched on. Heidenhain 216750-BF uses mounting type R with a flexible right-hand end piece. Its elastic coupling compensates for small alignment errors between the encoder and the machine guide. Electrical connection is through a 9-pin type 34S09 connector and an integrated 0.30 m cable. Supply voltage is 5 V (±5 %). The housing weighs approximately 3.0 kg. The complete Heidenhain 216750-BF identification must match the installed system. The encoder is intended as a direct replacement for matching LS 703 systems on turning, milling and grinding machines. Available directly from our warehouse in Germany.

Heidenhain 216750-BF

Specifications

Manufacturer Heidenhain
Product series LS 703 series
Type code 216750-BF
Measuring principle Incremental
Structure Sealed, large-profile aluminium housing
Measurement length 720 mm
Total length 870 mm
Accuracy class ±5.0 μm
Graduation period 20 μm
Output signal ~11 μApp sinusoidal current signals
Reference mark position 360 mm (central, 1 reference mark)
Mounting type R – flexible end piece, right
Electrical connection 9-pin type 34S09 connector, 0.30 m cable
Power supply 5 V (±5 %)
Scale material Glass
Protection rating IP 53
Cooling method Passive component; no active cooling
Weight Approx. 3.0 kg
