Heidenhain 223047-01
Price on request
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
2500 lines per revolution form the incremental graduation of the Heidenhain ROD-320-2500-H5. The encoder belongs to the ROD 320 product range and outputs square-wave signals with TTL levels. Its complete manufacturer identifier combines the series designation, line count and H5 version into a unique public identity. The line count denotes the documented resolution of the specific device, while the TTL designation separately and clearly defines its electrical signal type. The mechanical design includes its own bearing and wire-bail mounting. The shaft uses a 1:10 female taper. These two features describe mounting and shaft connection separately from the electrical signal form. The encoder has a 17-pin flange socket with pins for connection. The documented cable length is 0.21 m. The housing diameter is 87 mm and the housing length is specified as 57 ±0.3 mm. This results in a documented housing envelope of 87 × 87 × 57 mm. For the specific order, shipping from Germany to the United States and other international destinations is recorded together with these compact mechanical device data. The net weight is 0.21 kg. IP50 protection completes the variant profile of the ROD-320 encoder. Line count and TTL square-wave signals describe the signal side, while the female taper, wire-bail mounting, housing diameter and length describe the mechanical side. The 17-contact connection version remains a separate value. This keeps measuring principle, resolution, shaft geometry, mounting, connection and external dimensions individually specified. Product comparison is therefore based on the complete ROD-320-2500-H5 identifier and the associated electrical and mechanical facts.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Heidenhain |
|---|---|
| Product range | ROD 320 |
| Manufacturer/order/identification number | ROD-320-2500-H5 |
| Device type | Incremental encoder |
| Line count | 2500 |
| Output signals | Square-wave signals with TTL levels |
| Design | Encoder with integral bearing for wire-bail mounting |
| Shaft | 1:10 female taper |
| Housing diameter | 87 mm |
| Housing length | 57 ±0.3 mm |
| Electrical connection | Flange socket, pins, 17-pin |
| Cable length | 0.21 m |
| Degree of protection | IP50 |
| Dimensions | 87 × 87 × 57 mm (housing envelope; Ø 87 × 57 mm) |
| Weight | 0.21 kg net |
