i700 cabinet Dual servo inverter

Lenze E70ACMSE0054SA2ETR

€990.00

excl. VAT

Product condition:
Used, removed from an installation

The item comes from dismantled equipment. We have not carried out an electrical inspection or a comprehensive operational check. Signs of age, use, installation or removal may be present. 14-day right of return in the event of a defect. See Terms and Conditions

  • Available · Ships in approx. 3–6 business days
  • Urgent? Faster options such as direct or express shipping are often possible. Please state your required date when you request a quote or order.

Quantity: 1

Do you have any questions?

Personal service

We are happy to help with processing, shipping or individual quotations. Simply contact us:

Online and available Currently unavailable

International delivery

Available shipping options and net charges are calculated after the delivery country and postcode are entered at checkout. If no reliable rate is available, request an individual quotation.

Product description

EtherCAT communication and resolver feedback characterize the E70ACMSE0054SA2ETR version from Lenze. The dual servo inverter belongs to the i700 cabinet series and provides two power channels designated A and B. Both channels have the same current rating: the output current is 2.5 A each and the maximum output current is 5 A each. These specifications describe different load parameters and are listed separately. The DC input supply is specified as 565 V DC and belongs to the electrical input side of the inverter assembly.

This version has a rated power specification of 1.1 kW. In addition, the apparent output power for channels A and B is 1.6 kVA each. Rated power and apparent power are different parameters and are neither added together nor used interchangeably. EtherCAT provides the communication connection between the assembly and the control system. The resolver version is specified for encoder feedback, making the feedback type a separate feature of this complete type designation. The variant includes the Basic Safety version with STO.

Resolver feedback describes the encoder connection, while EtherCAT is the communication interface to the controller. These two features serve different purposes within the same assembly. As an IP20 built-in unit, the dual inverter is mechanically classified for installation in a control cabinet, with shipping from Germany to the United States and other international destinations tied to the specific order for this Lenze version. The two power channels, the DC input supply and the feedback type form distinct parts of the technical description.

For comparison with an existing assembly, the complete designation E70ACMSE0054SA2ETR, the output currents of both channels, EtherCAT and the resolver are therefore listed alongside one another. The ordering information also carries the material number 13440168. The device remains a dual servo inverter with two separately designated output channels within the i700-cabinet series.

Specifications

Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.

Identification

Manufacturer Lenze
Product series i700 cabinet
Manufacturer/order/identification number E70ACMSE0054SA2ETR
Device type Dual servo inverter

Performance data

Input voltage 565 V DC
Output current A / B 2.5 / 2.5 A
Maximum output current A / B 5 / 5 A
Rated power 1.1 kW
Apparent output power A / B 1.6 / 1.6 kVA

Interfaces

Communication EtherCAT
Encoder feedback Resolver

Installation and environment

Protection rating IP20
Mounting type Built-in unit

Dimensions and weight

Dimensions Approx. 60 × 280 × 220 mm
Weight Approx. 3 kg

Further details

Safety version Basic Safety – STO
Industrial production environment
