Product description

The Lenze E84AVSCE1522SX0 is a compact 8400 StateLine C variable frequency drive for controlled drive tasks in machines, conveyor systems and automated production plants. The version with Lenze article number 15843253 is designed for the 220-VAC class and delivers 1.50 kW rated power. The specified mains current is 13.7 A and the output current is 7.0 A. This makes the drive suitable for small to medium-sized motor applications with clearly defined power requirements and recurring motion sequences. The mains connection is 1/N/PE AC 230 V, while the motor output is configured as 3/PE AC. With dimensions of 70 × 270 × 199 mm and a weight of 2.1 kg, the unit can be planned precisely for existing cabinet fields. The StateLine-C platform supports parameterisation through an operator keypad or Lenze Engineer PC software. Settings can be stored permanently in a plug-in memory module and transferred when replacing the unit. The associated operating instructions cover devices from firmware V06.00 and include connection, commissioning, diagnostics and comprehensive fault management. The E84AVSCE1522SX0 is suitable as a type-identical replacement for existing 8400-StateLine-C drives and for retrofit projects that retain the mechanics, motor and control system. Before replacement, mains configuration, motor voltage, motor current, braking concept, control terminals, communication module and existing parameter set must be checked carefully. The complete identification number E84AVSCE1522SX0 is decisive because neighbouring power and voltage variants in the 8400 series are not automatically interchangeable. The clearly documented connection and enclosure data support spare-parts sourcing, cabinet planning and a structured, safe recommissioning process in time-critical industrial maintenance cases.

Lenze E84AVSCE1522SX0

Specifications

Manufacturer Lenze
Product series 8400 StateLine C
Manufacturer / order / identification number E84AVSCE1522SX0
Device type Variable frequency drive
Manufacturer article number 15843253
Rated power 1.50 kW
Voltage class 220 VAC
Mains current 13.7 A
Output current 7.0 A
Mains connection 1/N/PE AC 230 V
Motor output 3/PE AC
Dimensions 70 × 270 × 199 mm
Weight 2.1 kg
Firmware basis from V06.00
Parameterisation Keypad or Lenze Engineer
Parameter storage plug-in memory module
Control cabinet with PLC modules and automation components
Machine downtime in a production environment

Machine downtime?

Faster delivery

Is your machine down and do you require particularly fast delivery? Tell us directly. We will do everything possible to provide a quotation with the fastest available delivery and find a solution that matches your schedule.

Our highest priority is to keep your production processes running. Rely on our expertise and flexible service to minimise machine downtime effectively.

Contact us now!

Product safety

Manufacturer / EU responsible person

FAQ

Frequently asked questions

Contact us
What are the electrical ratings of the E84AVSCE1522SX0?

The Lenze variable frequency drive is rated for 220 VAC, 1.50 kW, 13.7 A mains current and 7.0 A output current.

What must be checked when replacing the Lenze 8400 StateLine C?

Mains configuration, motor data, braking concept, control terminals, communication module and parameter set must match the existing system.

Is there a guarantee?

Yes, we provide a 14-day functional guarantee for used items. This means the component must be operational when received.

Please note that the guarantee only applies when the warranty seal is undamaged.

If a defect occurs within 14 calendar days, please contact us in writing. Subject to availability, we will provide a replacement or refund the full purchase price after return.

Further details are provided in the terms and conditions supplied with your quotation.

How quickly do you dispatch and which shipping options are available?

We generally dispatch immediately - in many cases on the same working day. For particularly urgent requirements or machine downtime, we find a suitable solution as quickly as possible and provide a specific delivery window on request.

Express shipping or collection from our premises is also possible, depending on the situation. State your requirements during the ordering process or contact us directly.

We ship worldwide and work with reliable shipping partners, from parcel services to freight forwarding. Freight shipments normally require some preparation so the goods arrive safely and undamaged.

Which payment methods are available?

Payment is normally made by bank transfer against invoice. Payment is due within 10 calendar days of receiving the goods.

As a rule, we offer purchase on account for all customers. In individual cases, such as new customers or particularly high-value components, we may agree advance payment. This decision is made individually and communicated transparently.

Can we return items if they were ordered incorrectly?

Because we sell exclusively to business customers (B2B), there is no general right of return and no consumer right of withdrawal.

Please note that returns of functioning goods are generally excluded. In justified exceptional cases, we can assess an individual solution, but this is not the standard procedure.

Is there a discount when ordering several items?

For larger order quantities or several items of one type, we can offer individual discounts.

Simply send us a quick enquiry - we check availability and will gladly prepare a tailored quotation with quantity pricing.

Do you also purchase industrial spare parts?

Yes, we also purchase automation components, such as frequency inverters, PLC assemblies, panels, servo motors and CPUs. Components from Siemens, Lenze, Schneider Electric, Control Techniques or Heidenhain are especially sought after, and other brands are also possible.

The process is straightforward: email us an inventory list or overview photos at info@reha-industriekomponenten.de. We calculate a market-based purchase price and send you an offer.
