Lenze EVS9332-ES
Price on request
Do you require same-day delivery or express shipping with a defined delivery time for this item?
Please contact us!
The Lenze EMB9343-E belongs to the 9340 series and is a supply and feedback module for coupled Lenze drive systems. Its task is to centrally supply connected drive controllers via the DC bus and to feed regenerative braking energy back into the mains. This means that the device is functionally different from a braking unit, which simply converts regenerative energy into heat. For the installation version E, Lenze states protection class IP20 and operation in the control cabinet. The permissible mains voltage range is 3/PE AC 320 to 528 V at 48 to 62 Hz. The effective feed-in and regenerative power is 25.9 kW; the manual states 40.5 kW as the maximum value. On the mains side, 31.2 kVA apparent power, 45 A rated current and 67.5 A maximum current are documented. The DC link is specified as 48 A. For the sum of the shaft power connected via the drive controller, Lenze states 24 kW in motor operation and 30 kW in generator operation. The built-in device weighs 13.5 kg, is mounted vertically on the back wall of the control cabinet and has the power connection at the top. An external line filter type A is required for operation: EZN3A0055H045U for systems with UL approval or EZN3A0055H045 without UL approval. When replacing, the complete type number, line filter variant, line synchronization, DC bus, fuses, connection cross-sections and the load profile of the entire drive network must be checked. Likewise, existing drive controllers and the permissible motor and generator total power must match the planned 9340 system. An EMB9343-E is therefore only the right replacement if the existing system expressly provides for this energy recovery module including the associated filter and DC bus.
| Manufacturer | Lenze |
|---|---|
| Product series | 9340 |
| Manufacturer/order/identification number | EMB9343-E |
| Device type | Supply and feedback module |
| Design | Built-in device E |
| Protection class | IP20 |
| Mains voltage range | 3/PE AC 320–528 V |
| Mains frequency | 48–62 Hz |
| Feed-in/regenerative power | 25.9 kW |
| Maximum feed-in/regenerative power | 40.5 kW |
| Apparent power on the mains side | 31.2 kVA |
| Rated mains current | 45 A |
| Maximum mains current | 67.5 A |
| DC link current | 48 A |
| Motor shaft power | 24 kW |
| Regenerative shaft power | 30 kW |
| Required external line filter | EZN3A0055H045U (UL) or EZN3A0055H045 |
| mass | 13.5 kg |
