Mitsubishi Electric FX3U-16MT-DSS
Price on request
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Mitsubishi Electric groups 16 relay outputs in the compact MELSEC-F FX2N-16EYR-ES-UL expansion block. The module occupies output points only and receives its internal supply from the connected PLC base or extension unit. A vertically arranged terminal block with M3 screws provides the field wiring connections. The relay contacts switch external loads at up to 30 V DC or 240 V AC. For a resistive load, the limit is 2 A per output. The total current is limited to 8 A for either four or eight outputs per common. Inductive loads are rated up to 80 VA, while the stated reference value for the minimum load is 5 V DC and 2 mA. Switching from OFF to ON and from ON to OFF takes approximately 10 ms in each direction. Mechanical isolation separates the output circuits. A front LED lights when the corresponding relay coil is energised. The block draws 40 mA from the internal 5 V DC supply. 16 output indicators are arranged on the front, with one LED assigned to each relay channel. Current consumption, load limits, response times and terminal design form the electrical data of this variant. The product designation is MELSEC-F FX2N. Its enclosure is 40 mm wide, 90 mm high and 87 mm deep, so all three device axes are stated separately. Variant-specific net weight is approximately 0.3 kg. The complete FX2N model code identifies the relay-output version. The FX2N series, sixteen relay outputs and full ES-UL suffix together define the documented device identity. Delivery time is confirmed on request.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Mitsubishi Electric |
|---|---|
| Product range | MELSEC-F FX2N |
| Manufacturer/order/identification number | FX2N-16EYR-ES-UL |
| Device type | Output expansion block |
| Output points | 16 |
| Output type | Relay |
| Terminal design | Vertical terminal block with M3 screws |
| Supply | Internal supply from PLC base or extension unit |
| 5 V DC current consumption | 40 mA |
| External switching voltage | Maximum 30 V DC or 240 V AC |
| Resistive load per output | Maximum 2 A |
| Total current per common | Maximum 8 A for 4 or 8 outputs |
| Inductive load | Maximum 80 VA |
| Minimum load | 5 V DC, 2 mA (reference value) |
| Response time OFF→ON | Approx. 10 ms |
| Response time ON→OFF | Approx. 10 ms |
| Output isolation | Mechanical isolation |
| Assigned PLC series | FX1N, FX2N, FX3G, FX3U, FX1NC, FX2NC, FX3GC and FX3UC |
| Dimensions | 40 × 90 × 87 mm (W × H × D) |
| Weight | Approx. 0.3 kg net |
