Product description
With frame size 138, the Siemens 1PH6138-4CG40-Z belongs to the compact AC main spindle motors of the 1PH6 series. The 4CG4 power variant is listed for 28 kW at a rated speed of 2,000 U/min, with a corresponding rated torque of 134 Nm. These core drive data clearly distinguish this motor family from the 1.500-U/min versions in the same frame size. The motor uses separate ventilation and is assigned protection class IP54. The exact model reference specifies mounting arrangement IM B3, meaning a foot-mounted design for horizontal installation. Siemens documentation classifies 1PH6 motors as rotary induction motors and assigns the 4CG4 variant to main spindle drives. The complete manufacturer identifier, power rating, rated speed and actual mechanical design therefore remain the decisive parameters for selection and configuration. Motor code 161 also links the 4CG4 family to the corresponding selection in earlier Siemens drive documentation. Closely related versions in frame size 1PH6138 show dimensions of approximately 850 × 260 × 330 mm and a weight of around 100 kg. These figures are identified as series-based approximations because an attached encoder, fan, connection orientation and the actual version can alter the outside dimensions and mass. The installation situation should therefore be checked against the existing rating plate and mechanical interfaces. Connection orientation, shaft end and any installed feedback system also remain subject to inspection on the specific motor. The full product identifier 1PH6138-4CG40-Z is retained throughout; additional equipment features are not derived without concrete evidence. This allows the unit to be classified from its verified motor data and visible mounting and connection features.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | 1PH6 |
| Manufacturer/order/identification number | 1PH6138-4CG40-Z |
| Device type | AC main spindle motor |
| Motor design | Induction motor |
| Frame size | 138 |
| Rated power | 28 kW |
| Rated speed | 2,000 U/min |
| Rated torque | 134 Nm |
| Cooling method | Separate ventilation |
| Protection class | IP54 |
| Mounting arrangement | IM B3 |
| Motor code | 161 |
| Dimensions | approx. 850 × 260 × 330 mm (approximation for frame size 1PH6138) |
| Weight | approx. 100 kg (approximation for frame size 1PH6138) |
Related products
Go to shop
Siemens 1FK6060-6AF71-1TA0
Price on request
Siemens 1FK6063-6AF71-1AG0
€1,860.00
Siemens 1FK6083-6AF21-1TB9-Z
Price on request
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
Which core data identify the Siemens 1PH6138-4CG40-Z?
The 4CG4 variant is classified as an AC main spindle motor in frame size 138 with 28 kW, 2,000 U/min and 134 Nm.
Which mounting arrangement is specified for the 1PH6138-4CG40-Z?
The exact model reference specifies the foot-mounted IM B3 design; further equipment features are only adopted after checking the specific motor.
