Siemens 6EP1534-1SL01
Price on request
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
With an output voltage of 24 V DC and a rated current of 8 A, Siemens 6EP1333-4BA00 belongs to the SIMATIC PM 1507 load power supply range. The device designation PM 190 W 120/230 VAC identifies the specific version in the S7-1500 format. Two automatically switched rated voltage ranges are available on the input side: 120 V AC and 230 V AC. The permissible ranges extend from 85 to 132 V AC and from 170 to 264 V AC respectively. The line-frequency range is 45 to 65 Hz. At the two rated voltages, the input-current values are 3.7 A and 1.7 A. A regulated, galvanically isolated voltage of 24 V DC is present at the output. The rated output current is 8 A. During a power failure, the module maintains the rated value for at least 20 ms. The output side has electronic short-circuit protection with shutdown and automatic restart. Three front LEDs indicate operating, error and maintenance states. The mains connection and 24-V output are pluggable; the input uses screw terminals and the output uses spring-loaded terminals. The permissible conductor cross-section is 0.5 to 2.5 mm² in each case. The module mounts on the S7-1500 mounting rail. DIN-rail or wall mounting is not provided for this version. The enclosure has IP20 protection and protection class I with protective conductor. For horizontal mounting, the operating-temperature range is 0 to +60 °C; for vertical mounting it is 0 to +40 °C. The enclosure is 75 mm wide, 147 mm high and 129 mm deep. Its net weight is 0.74 kg.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product range | SIMATIC PM 1507 |
| Manufacturer/order/identification number | 6EP1333-4BA00 |
| Device type | stabilized load power supply |
| Supply system | single-phase AC supply |
| Rated input voltages | 120 V AC or 230 V AC with automatic range switching |
| Input-voltage ranges | 85–132 V AC or 170–264 V AC |
| Line frequency | 45–65 Hz |
| Input current | 3.7 A at 120 V AC; 1.7 A at 230 V AC |
| Rated output voltage | 24 V DC |
| Rated output current | 8 A |
| Power-failure buffering | at least 20 ms at rated output current |
| Short-circuit protection | electronic shutdown with automatic restart |
| Galvanic isolation | provided between input and output |
| Degree of protection | IP20 |
| Mounting | S7-1500 mounting rail; no DIN-rail or wall mounting |
| Operating temperature | 0 to +60 °C with horizontal mounting; 0 to +40 °C with vertical mounting |
| Dimensions | 75 × 147 × 129 mm (W × H × D) |
| Weight | 0.74 kg net weight |
Related products
Go to shop
Urgent requirement?
Shipping options
Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.
Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.
Contact us now!Product safety
Manufacturer / EU responsible person
Which input and output data apply to Siemens 6EP1333-4BA00?
The load power supply operates with 120 or 230 V AC at the input and automatic range switching. The output provides 24 V DC at a rated current of 8 A.
What are the dimensions and net weight of the PM-1507 module?
The enclosure measures 75 × 147 × 129 mm in width, height and depth. The net weight is 0.74 kg.
