Product description

The Siemens 6EP1436-3BA00 from the SITOP modular series is a stabilized industrial power supply for high-power 24-V-DC loads. The unit is supplied from a three-phase AC network at 400 to 500 V and provides 24 V DC at a rated output current of 20 A. This corresponds to a rated output power of 480 W. The regulated output voltage is suitable for supplying PLC components, operator panels, sensors, actuators and other DC loads in machinery and plant engineering. The power supply snaps onto a 35-mm DIN rail in accordance with EN 60715 and uses screw terminals. Its dimensions of 160 × 125 × 125 mm and net weight of 2 kg allow the existing control-cabinet layout to be checked unambiguously before replacement. Cooling is by natural convection; 50 mm clearance is specified above and below for heat dissipation. The permissible operating range extends from 0 to 70 °C with natural convection. The derating specified in the data sheet must be taken into account above 60 °C. When replacing an existing power supply, the complete 6EP1436-3BA00 order number, three-phase input voltage, output voltage and current, installation dimensions, terminal assignment and upstream protection must match. Neighbouring SITOP variants can differ in their input, output or equipment and therefore are not interchangeable merely because their housings look similar. This unit is suitable as a type-identical spare part for maintenance, repair and retrofit of existing control cabinets. REHA-Components supplies the Siemens 6EP1436-3BA00 for industrial maintenance and supports customers in matching the electrical and mechanical key data.

Siemens 6EP1436-3BA00

Specifications

Manufacturer Siemens
Product series SITOP modular
Manufacturer / order / identification number 6EP1436-3BA00
Device type Stabilized industrial power supply
Supply system 3-phase alternating current
Input voltage 400–500 V AC
Output voltage 24 V DC
Output current 20 A
Output power 480 W
Connection type Screw terminals
Mounting DIN rail EN 60715, 35 × 7.5/15 mm
Dimensions (W × H × D) 160 × 125 × 125 mm
Net weight 2 kg
Operating temperature 0 to 70 °C with natural convection
Control cabinet with PLC modules and automation components
Machine downtime in a production environment

Machine downtime?

Faster delivery

Is your machine down and do you require particularly fast delivery? Tell us directly. We will do everything possible to provide a quotation with the fastest available delivery and find a solution that matches your schedule.

Our highest priority is to keep your production processes running. Rely on our expertise and flexible service to minimise machine downtime effectively.

Contact us now!

Product safety

Manufacturer / EU responsible person

FAQ

Frequently asked questions

Contact us
What output does the Siemens 6EP1436-3BA00 provide?

The stabilized power supply provides 24 V DC at 20 A, corresponding to a rated output power of 480 W.

What must be checked when replacing the SITOP power supply?

Check the complete order number, the three-phase 400 to 500-V input network, 24 V DC and 20 A output, terminal assignment, upstream protection, DIN-rail mounting and installation space.

Is there a guarantee?

Yes, we provide a 14-day functional guarantee for used items. This means the component must be operational when received.

Please note that the guarantee only applies when the warranty seal is undamaged.

If a defect occurs within 14 calendar days, please contact us in writing. Subject to availability, we will provide a replacement or refund the full purchase price after return.

Further details are provided in the terms and conditions supplied with your quotation.

How quickly do you dispatch and which shipping options are available?

We generally dispatch immediately - in many cases on the same working day. For particularly urgent requirements or machine downtime, we find a suitable solution as quickly as possible and provide a specific delivery window on request.

Express shipping or collection from our premises is also possible, depending on the situation. State your requirements during the ordering process or contact us directly.

We ship worldwide and work with reliable shipping partners, from parcel services to freight forwarding. Freight shipments normally require some preparation so the goods arrive safely and undamaged.

Which payment methods are available?

Payment is normally made by bank transfer against invoice. Payment is due within 10 calendar days of receiving the goods.

As a rule, we offer purchase on account for all customers. In individual cases, such as new customers or particularly high-value components, we may agree advance payment. This decision is made individually and communicated transparently.

Can we return items if they were ordered incorrectly?

Because we sell exclusively to business customers (B2B), there is no general right of return and no consumer right of withdrawal.

Please note that returns of functioning goods are generally excluded. In justified exceptional cases, we can assess an individual solution, but this is not the standard procedure.

Is there a discount when ordering several items?

For larger order quantities or several items of one type, we can offer individual discounts.

Simply send us a quick enquiry - we check availability and will gladly prepare a tailored quotation with quantity pricing.

Do you also purchase industrial spare parts?

Yes, we also purchase automation components, such as frequency inverters, PLC assemblies, panels, servo motors and CPUs. Components from Siemens, Lenze, Schneider Electric, Control Techniques or Heidenhain are especially sought after, and other brands are also possible.
