SIMATIC S5 466 Isolated analog input module

Siemens 6ES5 466-3LA11

Price on request

Availability is checked individually.

Product condition:
Used, removed from an installation

The item comes from dismantled equipment. We have not carried out an electrical inspection or a comprehensive operational check. Signs of age, use, installation or removal may be present. 14-day right of return in the event of a defect. See Terms and Conditions

  • The estimated delivery time will be confirmed for the specific order.
  • Urgent? Faster options such as direct or express shipping are often possible. Please state your required date when you request a quote or order.

Do you have any questions?

Personal service

We are happy to help with processing, shipping or individual quotations. Simply contact us:

Online and available Currently unavailable

International delivery

The individual quotation states the shipping method and costs for the item and destination.

Product description

The Siemens 6ES5 466-3LA11 is an isolated analog input module from the SIMATIC S5 466 product series. The Siemens manual assigns the module to the S5-115U automation system and describes a selectable channel configuration: 16 single-ended channels or eight differential inputs, grouped in sets of four or two channels respectively. The module therefore acquires current and voltage signals across several industrial measurement ranges. The documented current ranges are 0 to 20 mA, 4 to 20 mA and ±20 mA. Voltage ranges extend from 0 to 1.25 V through 0 to 10 V and from ±1.25 V through ±10 V.

Digital representation can be selected as 12-bit two's complement, 11 bits plus sign or a 12-bit binary value. Siemens specifies instantaneous value decoding as the measurement principle, while conversion uses successive approximation. The typical conversion time is 25 µs per channel and the encoding time is 250 µs per measured value. A maximum cyclic scan time of 2 ms is specified for eight measured values. Input resistance is 10 MΩ for voltage measurement and 125 Ω for current measurement. Shielded signal cables may be up to 200 m long.

The module reports overflow and internal faults through status bits. Common-mode rejection is at least 70 dB. It uses an internal 5 V ±5 % supply and requires no external supply. Typical internal current consumption is 0.7 A and power dissipation is 3.5 W. Connection is through a 43-pin front connector. The complete 6ES5 466-3LA11 order number, isolated design and 16/8-channel configuration must all match when identifying the variant. The module measures 43 × 303 × 187 mm and weighs approximately 0.4 kg.

Specifications

Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.

Identification

Manufacturer Siemens
Product series SIMATIC S5 466
Manufacturer / order / identification number 6ES5 466-3LA11
Device type Isolated analog input module

Performance data

Current ranges 0–20 mA, 4–20 mA and ±20 mA
Voltage ranges 0–1.25 V; 0–2.5 V; 0–5 V; 1–5 V; 0–10 V; ±1.25 V; ±2.5 V; ±5 V; ±10 V
Power supply Internal 5 V ±5 %; no external supply
Current consumption 0.7 A internal, typical
Power dissipation 3.5 W, typical

Interfaces

Input configuration 16 single-ended or 8 differential inputs, selectable in groups
Input resistance 10 MΩ for voltage measurement; 125 Ω for current measurement
Front connector 43-pin

Dimensions and weight

Dimensions 43 × 303 × 187 mm (W × H × D)
Weight approx. 0.4 kg

Further details

Measurement types Current and voltage measurement
Digital representation 12-bit two's complement, 11 bits plus sign or 12-bit binary value
Conversion method Successive approximation
Conversion time 25 µs per channel, typical
Encoding time 250 µs per measured value
Scan time Maximum 2 ms for 8 measured values

Product status and export data

Product status (manufacturer) End of life since 01/10/2010
Commodity code 85389091
Country of origin Germany
Export list number (AL) N
ECCN N

Manufacturer information for order number 6ES5 466-3LA11, as of 21/10/2026. Not a statement about the individual unit supplied; does not replace an export control review.

Industrial production environment

Urgent requirement?

Shipping options

Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.

Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.

Contact us now!

Product safety

Manufacturer / EU responsible person

FAQ

Questions about 6ES5 466-3LA11

Contact us
Which input configurations does the Siemens 6ES5 466-3LA11 support?

The module processes either 16 single-ended channels or eight isolated differential inputs. Selection is made in groups of four or two channels respectively.

Which current and voltage ranges are documented?

The documented current ranges are 0–20 mA, 4–20 mA and ±20 mA. Voltage ranges cover 0–1.25 V through 0–10 V as well as the bipolar ranges ±1.25 V, ±2.5 V, ±5 V and ±10 V.
