Siemens 6ES7 407-0KR00-0AA0
€250.00
Shipping information
Do you require same-day delivery or express shipping with a defined delivery time for this item?
Please contact us!
Product description
Siemens 6ES7 405-0RA02-0AA0 is a PS 405 power-supply module for the SIMATIC S7-400 automation system. It supplies the S7-400 backplane bus from a DC source and is designed for rated input voltages of 24, 48 or 60 V DC. The 5-V backplane bus receives up to 20 A without a required base load. The module also supplies up to 1 A to the 24 V backplane bus and is no-load proof on that output. Rated input current is 7 A at 24-V DC, 3.2 A at 48 V DC and 2.5 A at 60 V DC. Siemens specifies a 20 ms ride-through time for short mains or voltage interruptions in accordance with the NAMUR recommendation. Maximum inrush current is 56 A with a half-value width of 1.5 ms. The outputs are short-circuit protected, and the primary and secondary sides are electrically isolated. Typical active power consumption is 168 W and typical power dissipation is 44 W. Two optional lithium AA backup batteries, each rated at 3.6 V and 2.2 Ah, can be installed. The PS 405 occupies two slots, measures 50 mm wide, 290 mm high and 217 mm deep and weighs approx. 1.3 kg. Siemens specifies protection class I with a protective conductor, overvoltage category II and an operating-temperature range of 0 to 60 °C. The electrical connection accepts three 1.5 mm² conductors, either solid or flexible with ferrules. Before replacement, compare the full order number, input voltage, backplane-bus load, installed backup batteries, protective-conductor routing, conductor cross-section and available rack width. This AA02 version is a precisely defined replacement for high-output, DC-powered S7-400 central racks.
Specifications
| Manufacturer | Siemens |
|---|---|
| Product series | SIMATIC S7-400 / PS 405 |
| Manufacturer/Order/Identification number | 6ES7 405-0RA02-0AA0 |
| Device type | PS 405 power-supply module with wide-range DC input |
| Rated input voltage | 24 V DC, 48 V DC or 60 V DC |
| Input current at 24 V DC | Rated value 7 A |
| Input current at 48 V DC | Rated value 3.2 A |
| Input current at 60 V DC | Rated value 2.5 A |
| Inrush current | Maximum 56 A, half-value width 1.5 ms |
| 5 V DC output | Maximum 20 A on the backplane bus; no base load required |
| 24 V DC output | Maximum 1 A on the backplane bus; no-load proof |
| Power-failure ride-through | 20 ms, in accordance with the NAMUR recommendation |
| Short-circuit protection | Provided |
| Active power consumption | Typically 168 W |
| Power dissipation | Typically 44 W |
| Backup battery | Optional 2 x lithium AA, each 3.6 V / 2.2 Ah |
| Electrical isolation | Primary and secondary sides electrically isolated |
| Protection class | Class I with protective conductor; overvoltage category II |
| Dimensions and slots | 50 x 290 x 217 mm; 2 slots |
| Weight and operating temperature | Approx. 1.3 kg; 0 to 60 °C |
Related products
Go to shop
Siemens 6ES7 416-3XL04-0AB0
€1,030.00
Siemens 6ES7 441-1AA03-0AE0
€620.00
Siemens 6ES7 463-2AA00-0AA0
Price on request
Machine downtime?
Faster delivery
Is your machine down and do you require particularly fast delivery? Tell us directly. We will do everything possible to provide a quotation with the fastest available delivery and find a solution that matches your schedule.
Our highest priority is to keep your production processes running. Rely on our expertise and flexible service to minimise machine downtime effectively.
Contact us now!Product safety
Manufacturer / EU responsible person
Which input voltages does Siemens 6ES7 405-0RA02-0AA0 support?
The PS 405 is designed for rated input voltages of 24 V DC, 48 V DC and 60 V DC.
How much current does the PS 405 supply to the S7-400 backplane bus?
The module supplies up to 20 A at 5 V DC and an additional maximum of 1 A at 24 V DC to the backplane bus.
