Siemens 6ES7414-3XM05-0AB0
€1,460.00
Shipping information
Do you require same-day delivery or express shipping with a defined delivery time for this item?
Please contact us!
Product description
The Siemens 6ES7 414-3XJ00-0AB0 is a powerful central processing unit from the SIMATIC S7-400 range for maintaining, expanding and modernising industrial control systems. As a CPU 414-3 DP, it combines extensive program memory resources with several integrated communication options. Users have 384 KByte of working memory for code and 384 KByte for data. The internal load memory comprises 256 KByte RAM and can be expanded to as much as 64 MByte with a FEPROM or RAM memory card. Two isolated RS-485 interfaces support MPI and PROFIBUS DP at transmission rates up to 12 MBaud. The first interface can manage up to 32 slaves as a DP master, while the second can manage up to 96 slaves. An additional slot is provided for the IF 964-DP interface module. This enables flexible integration into existing communication structures and distributed automation concepts. The configurable process image covers up to 8 KByte of inputs and 8 KByte of outputs. Short execution times starting at 0.1 microseconds for bit, word and fixed-point operations support fast control processes. Siemens specifies 0.6 microseconds for floating-point operations. The CPU occupies two slots in the S7-400 rack and measures 50 × 290 × 219 millimetres. With typical power dissipation of 7.5 watts and a weight of approximately 1.07 kilograms, it is designed for central and distributed automation structures. The peripheral address area of 8 KByte each for inputs and outputs provides capacity for extensive machine and plant configurations. The exact order number simplifies matching against existing plant documents, racks and spare-parts inventories. This gives maintenance teams a clearly identifiable replacement or expansion module for established S7-400 systems.
Specifications
| Manufacturer | Siemens |
|---|---|
| Product range | SIMATIC S7-400 |
| Manufacturer/order/identification number | 6ES7 414-3XJ00-0AB0 |
| Device type | CPU 414-3 DP central processing unit |
| Documented firmware version | V3.1 |
| Configuration | STEP 7 from V5.2 |
| Working memory | 384 KByte code / 384 KByte data |
| Internal load memory | 256 KByte RAM |
| Memory card expansion | FEPROM or RAM up to 64 MByte |
| Instruction execution | 0.1 µs for bit, word and fixed-point operations; 0.6 µs for floating-point operations |
| Peripheral address area | 8 KByte inputs / 8 KByte outputs |
| Process image | 8 KByte inputs / 8 KByte outputs, configurable |
| Integrated interfaces | 2 × RS 485 / PROFIBUS, isolated |
| MPI/PROFIBUS DP | Up to 12 MBaud; DP master and DP slave |
| DP master capacity | 1. interface max. 32 slaves; 2. interface max. 96 slaves |
| Interface expansion | IF 964-DP pluggable |
| Dimensions | 50 × 290 × 219 mm |
| Mechanical format | 2 slots |
| Weight | approx. 1.07 kg |
| Power dissipation | typically 7.5 W |
Related products
Go to shop
Siemens 6ES7 414-3EM07-0AB0
Price on request
Siemens 6ES7416-2XN05-0AB0
€690.00
Siemens 6ES7417-4XL04-0AB0
€690.00
Machine downtime?
Faster delivery
Is your machine down and do you require particularly fast delivery? Tell us directly. We will do everything possible to provide a quotation with the fastest available delivery and find a solution that matches your schedule.
Our highest priority is to keep your production processes running. Rely on our expertise and flexible service to minimise machine downtime effectively.
Contact us now!Product safety
Manufacturer / EU responsible person
Which communication interfaces does the Siemens 6ES7 414-3XJ00-0AB0 provide?
The CPU has two isolated RS-485 interfaces for MPI and PROFIBUS DP at transmission rates up to 12 MBaud. An IF-964-DP interface module can also be installed.
How much working memory does the CPU 414-3 DP provide?
The user program has 384 KByte of code memory and 384 KByte of data memory available. The internal load memory additionally comprises 256 KByte RAM.
