SIMATIC S7-1500TF Technology CPU

Siemens 6ES7518-4UP00-0AB0

Price on request

Availability is checked individually.

Product condition:
Used, removed from an installation

The item comes from dismantled equipment. We have not carried out an electrical inspection or a comprehensive operational check. Signs of age, use, installation or removal may be present. 14-day right of return in the event of a defect. See Terms and Conditions

  • The estimated delivery time will be confirmed for the specific order.
  • Urgent? Faster options such as direct or express shipping are often possible. Please state your required date when you request a quote or order.

Do you have any questions?

Personal service

We are happy to help with processing, shipping or individual quotations. Simply contact us:

Online and available Currently unavailable

International delivery

The individual quotation states the shipping method and costs for the item and destination.

Product description

The CPU 1518TF-4 PN/DP combines the control functions of the SIMATIC S7-1500TF with several integrated communication paths. Under the Siemens 6ES7518-4UP00-0AB0 order number, this version includes three PROFINET interfaces and a PROFIBUS-DP connection. It forms the central processing unit for control programs, data and technology objects within the modular automation system.

The PROFINET connections serve different purposes. One IRT interface has two ports; separate interfaces for PROFINET RT and basic services are also available. The PROFIBUS-DP connection adds a dedicated fieldbus access point to these Ethernet-based communication paths. Configuration therefore needs to account for both the respective protocol and the function of each connection. The number of interfaces must be distinguished from the number of their physical ports.

The work memory is divided into 9 MB for the program and 60 MB for data. This division describes two different CPU memory areas. The processing time for bit operations is 1 ns; this individual figure does not specify the cycle time of a complete user program. The technology version supports up to 192 technology objects. Its functional scope includes motion control tasks such as synchronized axes, kinematics and cam functions.

The electrical supply is 24 V DC. The permissible supply voltage range is 19.2 to 28.8 V DC. For the specific quotation, with shipping to the United States and other international destinations arranged for the individual order, the module is identified by the complete order number 6ES7518-4UP00-0AB0 and the CPU version 1518TF-4 PN/DP. Rounded overall dimensions of approximately 180 × 150 × 130 mm are used for the external dimensions. The weight is specified as an approximate value of 2.1 kg.

Specifications

Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.

Identification

Manufacturer Siemens
Product series SIMATIC S7-1500TF
Manufacturer / order / identification number 6ES7518-4UP00-0AB0
Device type Technology CPU

Performance data

Rated supply 24 V DC
Supply voltage range 19.2–28.8 V DC

Interfaces

PROFINET interfaces 3
PROFIBUS-DP interfaces 1
PROFINET-IRT connection Two ports

Dimensions and weight

Dimensions approx. 180 × 150 × 130 mm
Weight approx. 2.1 kg

Further details

CPU version 1518TF-4 PN/DP
Program work memory 9 MB
Data work memory 60 MB
Bit operation time 1 ns
Technology objects max. 192

Product status and export data

Product status (manufacturer) Discontinued since 01/10/2026
Commodity code 85371091
Country of origin Germany
Export list number (AL) N
ECCN 9N9999

Manufacturer information for order number 6ES7518-4UP00-0AB0, as of 20/10/2026. Not a statement about the individual unit supplied; does not replace an export control review.

Siemens SIMATIC S7 error codes

View all 533 error codes
Industrial production environment

Urgent requirement?

Shipping options

Send us the complete type number, destination and requested timing. We will assess whether the specific item can be supplied and which shipping options can be offered.

Any stated dispatch or delivery date is an estimate unless expressly confirmed as binding.

Contact us now!

Product safety

Manufacturer / EU responsible person

FAQ

Questions about 6ES7518-4UP00-0AB0

Contact us
How is the work memory divided?

The CPU has 9 MB of program work memory and 60 MB of data work memory.

Ordering and service

What applies if an item develops a defect within 14 days?

For the condition categories “Used, removed from an installation” and “New, old stock”, the contractual 14-day right of return in the event of a defect applies. The defect must occur within 14 calendar days after delivery and be reported in text form within the same period.

In particular, the REHA tamper-evident seal must remain fully intact and our RMA approval is required before return. In an accepted case, we decide between replacement and refund. Details in Section 11 of the Terms.

Which shipping methods and delivery times are available?

The shipping method, shipping cost and estimated delivery time are confirmed for the specific order. Depending on the item, destination and urgency, we can check parcel, express or freight shipping as well as collection.

A delivery date is binding only if we expressly confirm it as binding.

Which payment terms apply?

The payment terms stated in the checkout or order confirmation apply. Depending on the order and customer, payment is made in advance or against invoice.

International deliveries and deliveries to new customers are generally made against advance payment unless we expressly confirm another payment arrangement.

Can I return an item ordered incorrectly or found incompatible?

No. There is no general B2B right of return, exchange, cancellation or withdrawal. Incorrect or duplicate orders and a lack of suitability or compatibility with the customer’s installation are not covered by the contractual 14-day right of return in the event of a defect. Details in Section 12 of the Terms.

Can I request individual pricing for several items?

You may request an individual quotation for several items or larger quantities. We then check availability and pricing for the specific requirement; there is no entitlement to a quantity discount. Open the quick enquiry.

Do you also purchase industrial spare parts?

Yes. You can offer us automation and drive components for purchase. Please provide complete type numbers, quantities, condition details and photographs where possible.

After review, we will tell you whether a purchase is possible and on which terms. Learn more about selling industrial stock.

Receive a quotation by email

Request availability

Use the form to request item-specific price, availability and estimated delivery information.
