Product description
Siemens 6RA2178-6DS20-1A is a regulated DC converter from the SIMOREG K 6RA21 range. The complete stocked-item identifier ends in -1A and remains essential for spare-part identification. Within the documented product family, 6RA2178-6DS20 denotes a three-phase single-quadrant version for 380 V AC input, up to 460 V DC output and 300 A rated DC current. Power conversion uses a B6C thyristor bridge. Power, control and regulation sections form one compact assembly. The Siemens operating instructions for three-phase 6RA21 single-quadrant converters place the 300-A version in the same enclosure group as the 170 to 375 A units. The corresponding outline drawing specifies 270 mm width, 500 mm height and 300 mm depth. External dimensions are consequently stated as 270 × 500 × 300 mm in W × H × D order. The documented protection degree of the open-format unit is IP00; a closed enclosure is not part of the converter housing. The technical-data table lists 27 kg for 6RA2178-6DS20, and a product page for the base version confirms the same figure. Dimensions and weight refer to the individual open-format converter, excluding shipping packaging, external commutation chokes, additional cables and cabinet components. A replacement comparison must consider the complete -1A identifier together with input voltage, output ratings, single-quadrant operation, bridge circuit, enclosure dimensions and connection environment. Other SIMOREG units with similar designations may differ in current rating, mains voltage, operating mode or execution. Installation, connection and commissioning therefore require qualified personnel and the applicable Siemens and machine documentation.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | SIMOREG K 6RA21 |
| Manufacturer / order / identification number | 6RA2178-6DS20-1A |
| Device type | Controlled DC converter unit |
| Function | Armature supply for DC drives |
| Control mode | Single-quadrant operation |
| Power circuit | B6C bridge circuit |
| Mains connection | Three-phase, 380 V AC |
| Output voltage | Up to 460 V DC |
| Rated DC current | 300 A |
| Power control element | Thyristors |
| Construction | Power, control and regulation sections in one compact unit |
| Version code | MRE-GCEF 6S20 |
| Dimensions | 270 × 500 × 300 mm (W × H × D) |
| Weight | 27 kg |
