Siemens 6SL3040-1MA01-0AA0
€520.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Siemens 6SL3000-0BE23-6AA0 is an Active Line Filter from the SINAMICS S120 product range. The complete product number assigns the filter to a 36 kW Active Line Module power class. This power class must not be confused with the electrical rated current of the filter, which is 67 A AC. The documented line-voltage range is 3 AC 380 V −10 % to 480 V +10 %. A short-time undervoltage down to −15 % is specified for less than 1 min. Line-frequency range is 47–63 Hz. For this exact version, the Siemens Equipment Manual states 250 W power loss and a weight of 16 kg. For the mechanical arrangement, the Siemens assignment table gives core dimension a as 130 mm, core width w as 100 mm and core dimension c as 15 mm. Maximum height is 245 mm and maximum length is 526 mm. In addition, the variant-specific technical record assigns 130 mm width, 480 mm height and 245 mm depth to the complete filter enclosure. Complete overall dimensions are therefore 130 × 480 × 245 mm (W × H × D). The differing drawing values describe core, maximum and enclosure dimensions and are not interchangeable. For replacement and installation, the complete product number, 36-kW assignment, voltage range and rated current must be considered together. Other filters in the same range have different current, power and dimensional data. Dimensions and weight refer to the individual filter without connection cables, other S120 components or shipping packaging.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | SINAMICS S120 |
| Manufacturer/order/identification number | 6SL3000-0BE23-6AA0 |
| Device type | Active line filters |
| Mains voltage | 3 AC 380 V −10 % to 480 V +10 % |
| Short-term undervoltage | up to −15 % for less than 1 min |
| Mains frequency | 47–63 Hz |
| Rated current | 67 A AC |
| Power loss | 250 W |
| Core dimension a | 130 mm |
| Core width w | 100 mm |
| Core dimension c | 15 mm |
| Maximum height | 245 mm |
| Maximum length | 526 mm |
| Dimensions | 130 × 480 × 245 mm (W × H × D) |
| Weight | 16 kg |
