Siemens 6AV6646-1AA22-0AX0
€670.00
International delivery
The individual quotation states the shipping method and costs for the item and destination.
Product description
Siemens 6SL3000-0DE25-5AA1 is a three-phase HFD mains reactor for a 55 kW Active Line Module in SINAMICS S120 and SIMODRIVE drive systems. Siemens describes an effective rated current of 103 A and power loss of 350 W for this version. The reactor belongs to the mains-side power path of a controlled infeed. Its documented technical functions include limiting low-frequency mains feedback and mains harmonic currents, as well as storing energy for step-up operation. Oscillation damping within the converter system is also described in combination with the documented damping resistor. The mains connection is identified by 1U1, 1V1 and 1W1; the load side is identified by 1U2, 1V2 and 1W2. Screw connections up to 70 mm² are documented for the 55 kW version. Tightening torque for the mains conductors is 7 Nm, while the protective-conductor connection is specified as 70 mm² and 3.5 Nm. Terminals 1, 2, 3 and PE are assigned to the damping resistor. Any mounting position is documented. For mechanical planning, the exact product record specifies 150 mm width, 290 mm height and 330 mm depth. Complete external dimensions are therefore 150 × 290 × 330 mm. Two exact product sources confirm a device weight of approximately 27.2 kg. Dimensions and weight refer to the individual reactor without shipping packaging. Type number, device type, system assignment, power class, current value, terminal arrangement and enclosure format form the documented variant data set. The specification table concludes with Dimensions and Weight.
The item supplied will have the stated manufacturer or type number and the stated condition category. Serial number, manufacturing date, labels, colour, packaging and normal signs of use or storage may differ. Specifications
Unless expressly confirmed, technical information is provided to identify the device type. The complete manufacturer or type number is decisive.
| Manufacturer | Siemens |
|---|---|
| Product series | SINAMICS S120 / SIMODRIVE |
| Manufacturer / order / identification number | 6SL3000-0DE25-5AA1 |
| Device type | HFD mains reactor |
| System assignment | Active Line Module |
| Power class | 55 kW |
| Rated current | 103 A effective |
| Power loss | 350 W |
| Mains connection | 1U1, 1V1, 1W1 |
| Load connection | 1U2, 1V2, 1W2 |
| Mains-side conductor cross-section | 70 mm² screw connection |
| Mains-side tightening torque | 7 Nm |
| Protective-conductor connection | 70 mm², 3.5 Nm |
| Damping-resistor connection | Terminals 1, 2, 3 and PE |
| Mounting position | Any |
| Dimensions | 150 × 290 × 330 mm (W × H × D) |
| Weight | 27.2 kg |
